HCT02.1E-W0025-A-03-B-L8-2S-D1-D1-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911329656
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
34 Seconds
The Bosch Rexroth Indramat HCT02.1E-W0025-A-03-B-L8-2S-D1-D1-NN-FW is part of the HCT Multi Axis Drive Controllers series and offers a rated power of 25 kW. This multi-axis drive controller features 32 digital inputs, 16 digital outputs, and has a continuous output current of 35 A. It supports SERCOS III master communication, comes with IP20 protection, and uses air cooling provided by an integrated blower.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HCT02.1E-W0025-A-03-B-L8-2S-D1-D1-NN-FW is a multi-axis drive controller produced by Bosch Rexroth Indramat within the HCT Multi Axis Drive Controllers series. The unit coordinates several servo axes from a central rack-mounted platform and distributes DC-bus energy to each inverter section, making it a core element in modular motion systems such as packaging lines, pick-and-place gantries, and material-handling cells. By combining power conversion, axis control, and field communication in a single enclosure, it simplifies cabinet wiring for industrial automation.
The feeding section accepts a three-phase input of 3 x AC 200 to 500 V, covering common line voltages with a tolerance of ±10%. From this supply, the controller delivers up to 25 kW to the shared DC link, while the X5.1 channel can sustain 35.0 A of continuous motor current; auxiliary channels X5.3 and X5.4 each provide 14.0 A. Operation at these current levels produces about 850 W of internal loss, and an integrated blower moves 310 m³/h of air through the heat sink. The basic control design includes an embedded PC based on an LX 800 processor, a standard I/O set, four encoder ports, four probe inputs, and SERCOS III master communication for tight multi-axis synchronization.
The housing measures 455 × 320 × 191 mm and weighs 11.70 kg, so it can be mounted on a back panel without lifting equipment. Its enclosure rating of IP 20 limits use to protected cabinets, while a short-circuit current rating of 42000 A rms matches high-capacity feeder circuits. The controller also provides thirty-two digital inputs and sixteen digital outputs, and two DEA40.1 option cards can double these counts for more complex interlocking schemes. Forced-air cooling, moderate mass, and compact size help preserve clear cabinet layouts and reduce thermal interaction with adjacent equipment.
Frequently Asked Questions about HCT02.1E-W0025-A-03-B-L8-2S-D1-D1-NN-FW:
Q: What is the continuous output current available on channel X5.1 for the HCT02.1E-W0025-A-03-B-L8-2S-D1-D1-NN-FW?
A: This drive controller provides a continuous output current of 35.0 A on channel X5.1.
Q: How is the HCT02.1E-W0025-A-03-B-L8-2S-D1-D1-NN-FW cooled during operation?
A: The unit is cooled by internal air circulation through an integrated blower, with a forced cooling capacity of 310 m³/h.
Q: Does the HCT02.1E-W0025-A-03-B-L8-2S-D1-D1-NN-FW support SERCOS III Master communication?
A: It supports SERCOS III Master communication, enabling integration with compatible automation systems.
Q: How many digital inputs and outputs are available on the HCT02.1E-W0025-A-03-B-L8-2S-D1-D1-NN-FW?
A: The controller is equipped with 32 digital inputs and 16 digital outputs for versatile I/O capabilities.
Q: What is the rated power output of the HCT02.1E-W0025-A-03-B-L8-2S-D1-D1-NN-FW drive controller?
A: The rated power for this model is 25 kW, suitable for multi-axis drive tasks.
