HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911329659
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
13 Seconds
The Bosch Rexroth Indramat HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW is part of the HCQ Micro Controls series and has a rated power of 25 kW with a mass of 11.7 kg. It features 32 digital inputs, 16 digital outputs, and supports SERCOS III master communication. The product has a degree of protection rated at IP20 and operates with a mains voltage of 3 x AC 200 to 500 V.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW belongs to the HCQ Micro Controls series manufactured by Bosch Rexroth Indramat. It functions as a feed power supply with an embedded PC based on the LX 800 platform, so one unit can supply both control processing and three-phase power for connected drive sections. The integrated SERCOS III master interface supports motion coordination and field I/O exchange, while the Basic control section in design 1 handles voltage conversion and centralized machine control inside the cabinet. This arrangement keeps control, communication, and power functions in a single housing for compact automation layouts.
Rated output is 25 kW when the unit is supplied from 3 x AC 200 to 500 V mains within a plus or minus 10 percent tolerance. The rectifier accepts grid frequencies of 50 to 60 Hz and draws a continuous UL-listed input current of 44.0 A. The housing has an IP 20 enclosure rating, so the unit is intended for protected indoor installation inside a control cabinet rather than open mounting on the machine. It also provides 32 digital inputs, 16 digital outputs, five encoder channels, and four probe interfaces for machine feedback and signaling. Those interfaces allow the controller to receive switch states, encoder signals, and probe events directly from connected equipment. An integrated blower provides internal air cooling, and the housing measures 191 mm deep, 320 mm wide, and 455 mm high.
The inverter section supplies 3 x AC 0 to 500 V to downstream drives and has a short-circuit withstand rating of 42000 A rms for UL-compliant installations. That output allows the supply stage to feed connected axes from a common source while matching the electrical range expected by compatible drive modules. The unit has a transport mass of 11.70 kg, and upstream protection requires a class J fuse rated at 60 A to clear faults quickly. A DEA40.1 option is installed in the first expansion slot, while the second slot remains open for additional interface hardware.
Frequently Asked Questions about HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW:
Q: What is the mains connecting voltage range for the HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW controller?
A: This controller supports a mains connecting voltage range of 3 x AC 200 to 500 V, allowing flexible integration with various power systems.
Q: How many digital inputs and outputs are provided on this HCQ Micro Controls unit?
A: The HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW offers 32 digital inputs and 16 digital outputs for control and signal interfacing.
Q: What cooling method is used in the HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW controller?
A: Air cooling is utilized via an internal integrated blower to maintain optimal operating temperature.
Q: What is the degree of protection rating for the HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW?
A: This model features an IP 20 degree of protection, providing basic protection against intrusion of solid objects.
Q: Does the HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW include a SERCOS III master interface?
A: A SERCOS III master is included in this unit for seamless communication with other automation components.
