HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911322825
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
11 Seconds
The Bosch Rexroth Indramat HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW is part of the HCQ Micro Controls series and features a rated power of 25 kW with a rated input current of 44 Amps. This unit operates with a mains connecting voltage of 3 x AC 200 to 500 V and has an air cooling mode through an integrated blower. It provides a degree of protection rated at IP20 and has physical dimensions of 455 mm in height, 320 mm in width, and 191 mm in depth.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW is a micro control power module produced by Bosch Rexroth Indramat within the HCQ Micro Controls series. It acts as a power supply, delivering regulated three-phase energy to downstream inverters and motion controllers used in machining cells, packaging lines, and other automated stations. An onboard Embedded PC based on the LX 800 architecture supports parameter handling and diagnostics without external gateways, which allows local access to operating data and status information. The basic control section keeps the unit focused on stable power conversion rather than direct axis regulation for individual motors.
The module is sized for a continuous load of 25 kW, allowing it to supply several medium-frame servo drives from a single cabinet position. It accepts utility power over a wide range of 3 x AC 200 to 500 V, so it can be connected to either 230 V or 460 V plant service without tap changes. At full rating, it draws a nominal 44.0 A, and its input synchronizes automatically to line frequencies from 50 to 60 Hz. Cooling air is moved by an integrated blower to maintain component temperatures during operation. The enclosure is rated IP20, which helps protect against finger contact and solid objects but requires mounting in a clean, dry cabinet.
On the drive side, the converter generates 3 x AC 0 to 500 V so downstream axis inverters can receive the voltage needed for controlled motor operation. Upstream protection is provided by a 60 A Class J fuse, and the assembly has a fault-withstand capacity of 42,000 A rms for coordination with high-interrupt service breakers. The housing weighs 11.70 kg, and its 455 mm height, 320 mm width, and 191 mm depth help keep control panels shallow. Those dimensions also leave room for adjacent drive modules and cable routing inside compact cabinets, which is useful where panel space is limited.
Frequently Asked Questions about HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW:
Q: What is the mains connecting voltage range for the HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW?
A: The HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW operates with a mains connecting voltage of 3 x AC 200 to 500 V.
Q: What is the rated power of the HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW?
A: This unit has a rated power output of 25 kW for delivering robust performance in industrial settings.
Q: How is the HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW cooled?
A: The device uses internal air cooling through an integrated blower to regulate its temperature.
Q: What output voltage does the HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW provide?
A: The HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW offers an output voltage range of 3 x AC 0 to 500 V.
Q: What type and rating of branch circuit protection fuse does the HCQ02.1E-W0025-A-03-B-L8-1N-NN-NN-NN-FW use?
A: It is equipped with a branch circuit protection fuse rated at 60 A, class J.
