The Bosch Rexroth Indramat FCS01.1E-W0006-A-02-NNBV is part of the FCS Frequency Converters series and operates with a rated capacity of 0.55 kW and a maximum current of 6 Amps. It features sensorless vector control mode, an internal air cooling method through an integrated blower, and has an IP20 degree of protection. This frequency converter supports a mains connecting voltage of 1 x AC 200 to 240 Volts with a maximum output frequency of 400 Hz.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The FCS01.1E-W0006-A-02-NNBV belongs to the FCS Frequency Converters series manufactured by Bosch Rexroth Indramat. As an AC frequency converter, it is installed between the mains and a three-phase induction motor to vary speed and torque in small-power automation axes. It is intended for conveyors, pumps, and light processing equipment where adjustable motor speed is needed without external position feedback.
This converter accepts a single-phase input of 1 × AC 200…240 V and then synthesizes motor voltage with a linear V/f characteristic that extends to a maximum output frequency of 400 Hz. The internal power stage is rated for a continuous phase current of 6 A, and the insulated-gate drivers can switch at carrier frequencies up to 16 kHz to reduce motor acoustic noise. Rated mechanical power is 0.55 kW, which matches small IEC frame motors. Control is executed in sensorless vector mode, so stator flux is calculated from bus measurements rather than encoder data. Cooling air is drawn through an integrated blower, allowing use inside compact IP20 cabinets. Frame size B and design version 1 set the mechanical envelope and mounting points. A DC link connection supports shared energy operation, an external braking resistor can be connected to the built-in brake transistor, and the logic and control circuits are maintained by an auxiliary 24 V DC supply.
For short transients, the inverter can deliver 200% for 5 s or sustain 150% for 60 s, giving additional torque during acceleration or load shocks. The DC link operates at 400 V, enabling rapid energy exchange with neighboring drives on the same bus line. The degree of protection is IP20, so the unit must be mounted in a clean electrical enclosure. The product is part of line 1 of the platform, which places it in the same control family as related models in this range.
Frequently Asked Questions about FCS01.1E-W0006-A-02-NNBV:
Q: What type of braking resistance does the FCS01.1E-W0006-A-02-NNBV converter use?
A: The FCS01.1E-W0006-A-02-NNBV supports external braking resistance for managing excess energy during deceleration.
Q: Which control mode is implemented in the FCS01.1E-W0006-A-02-NNBV frequency converter?
A: This model features a sensorless vector control mode for precise motor speed and torque regulation.
Q: How is the FCS01.1E-W0006-A-02-NNBV frequency converter cooled?
A: Air cooling is achieved internally using an integrated blower to maintain temperature.
Q: What is the rated capacity of the FCS01.1E-W0006-A-02-NNBV?
A: The rated capacity of this frequency converter is 0.55 kW.
Q: What is the maximum output frequency for the FCS01.1E-W0006-A-02-NNBV?
A: The device can operate at a maximum output frequency of 400 Hz for demanding applications.
