The Bosch Rexroth Indramat FCS01.1E-W0005-A-02-NNBV is part of the FCS Frequency Converters series and is designed for use with a single- or three-phase AC input voltage of 200 to 240 V. This frequency converter supports a rated capacity of 0.37 kW, can handle a maximum current of 5 A, and features air cooling through an integrated blower. It offers a maximum output frequency of 400 Hz, a degree of protection rated at IP20, and an integrated brake transistor.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The FCS01.1E-W0005-A-02-NNBV frequency converter is manufactured by Bosch Rexroth Indramat within the FCS Frequency Converters series. Designed for cabinet installation, it interfaces with single-phase or three-phase mains and an intermediate DC link to supply adjustable AC power to small industrial motors. By modulating output frequency and voltage, the converter enables precise speed regulation, controlled acceleration, and coordinated braking in automated material-handling or processing equipment.
Released as design version 1 within line 1 of the converter platform, the housing carries an IP20 protection rating and uses internal air cooling with an integrated blower. During operation, the device rectifies the input supply to a DC link that tracks the mains at 1.41 times the input voltage before the inverter stage rebuilds up to 400 Hz of motor frequency. Pulse-width modulation is produced between 3 kHz and a ceiling of 16 kHz, allowing acoustic and dynamic performance to be tuned for the application. The converter delivers a continuous current of up to 5 A, and at that current it supports a rated mechanical output of 0.37 kW. A built-in brake transistor directs excess energy to an external resistor during deceleration events.
Short-term overload capability is provided for torque peaks: it can supply 200% of rated current for 5 seconds and 150% for 60 seconds without tripping. The mains connection accepts 200–240 V AC with a tolerance of ±10 %, and the converter operates at 50/60 Hz. The electronics synchronize gating so that motor output can start at 0 Hz and ramp smoothly to the programmed maximum. Because the braking resistor is external, it can be matched to the required duty cycle, and the embedded DC 24 V supply keeps the control electronics active during line disturbances.
Frequently Asked Questions about FCS01.1E-W0005-A-02-NNBV:
Q: What kind of braking system does the FCS01.1E-W0005-A-02-NNBV frequency converter use?
A: The FCS01.1E-W0005-A-02-NNBV is designed with external braking resistance and features an integrated brake transistor.
Q: What input phase options are available for the FCS01.1E-W0005-A-02-NNBV?
A: This frequency converter supports both single-phase and three-phase AC input.
Q: How is the FCS01.1E-W0005-A-02-NNBV frequency converter cooled?
A: The cooling method on this model uses internal air cooling through an integrated blower.
Q: What is the maximum output frequency supported by the FCS01.1E-W0005-A-02-NNBV?
A: The maximum output frequency is 400 Hz, suitable for various motor control scenarios.
Q: What level of environmental protection does the FCS01.1E-W0005-A-02-NNBV offer?
A: This model provides a degree of protection rated at IP20, offering basic protection against solid objects.
