DKS01.1-W030B-RS01-02

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911265275
  • Call for Expedited Shipping and Product Condition Options
The DKS01.1-W030B-RS01-02 DKS AC Servo Drive is manufactured by Rexroth, Indramat, Bosch. The compact controller has a current rating of 30 A and a power requirement of 4.5 kVA. This controller also has a supply voltage of 230 V and reduced noise emission.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DKS01.1-W030B-RS01-02

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911265275
  • Call for Expedited Shipping and Product Condition Options
The DKS01.1-W030B-RS01-02 DKS AC Servo Drive is manufactured by Rexroth, Indramat, Bosch. The compact controller has a current rating of 30 A and a power requirement of 4.5 kVA. This controller also has a supply voltage of 230 V and reduced noise emission.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a DKS01.1-W030B-RS01-02 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DKS01.1-W030B-RS01-02 is an identical digital servo drive from Indramat. The servo drive is one in the inaugural DKS01 series. The initial unit is covered by the class IP 10 per DIN 40 050. The unit is cased in an enclosure that can only be accessed deliberately or by objects lower than 50mm in diameter. It is also covered by the insulation class of C per DIN 570 110. Its numbering is indicative of its unique basic configurations. The DKS01.1-W030B-RS01-02 has DSF or Revolver as its encoder type and MDD as its motor type. It has a 30A rated current. While the continuous current stays at 15[10]A, 300V is the internal bus DC voltage.

The servo drive has single phase and triple phase as its electrical connection. The frequency is around 50Hz and 60Hz while the PWM frequency is 18Hz. The input voltage of the DKS01.1-W030B-RS01-02 drifts between 1 x 230 (±10%)V or 3 x 230 (±10%)V. Its rated power, however, is determined by the combination of the motor servo drive. When the DKS01.1-W030B-RS01-02 is at maximum loading, the power requirement is 3,5 KVA or 4,5 KVA. The Bleeder continuous power also known as the regenerated power is 0.3kW while its Bleeder peak power otherwise known as the Bleeder regenerated power is 5kW. The drive loses  power when it is loaded to maximum except when at Bleeder 230W or 195W.

At rated specifications, the permissible ambient temperature of the unit is +5⁰C to +45⁰C while temperatures should range between +30⁰C to +80⁰C when in storage and shipping. Elevation levels should be 1000m above sea level at maximum without derating. Humidity classification of the DKS01.1-W030B-RS01-02 should be  F per DIN 40 040 at maximum humidity. The drive weighs just about 11kg. This unit can be shipped globally with a one-year warranty period from Wake Industrial.

DKS01.1-W030B-RS01-02 Documents

  • DKS011W030BRS0102
  • DKS01.1 W030B RS01 02
  • DKSO1.1-WO3OB-RSO1-O2

DKS01.1-W030B-RS01-02 Technical Specifications

Current Rating: 30 A
Noise Emission: reduced
Power Requirement: 4.5 kVA
Supply Voltage: 230 V
