Product Description

The DKR04.1-W300N-BA01-01-FW drive controller manufactured by Bosch Rexroth has a line code of 4 and a version code of 1. The drive controller must not be operated or mounted if it is faulty or damaged. The unit should not be used underwater or when there is high temperature fluctuation. The firmware for the product should be bought separately. The device has a control voltage rating of 230VAC +/-10%. It may produce a high electrical voltage because of one or more wrong connections. The installation must be done according to the EMC requirements. The protective connection should encompass a copper conductor with a minimum cross-sectional area of 10mm².

The drive controller must be connected with ground wire before startup. The built-in monitor helps to eliminate most of the faulty movements of the controller. The product weighs close to 150kg. The device uses an analog interface for command communications. It is intended to be used for digital intelligent control of the manufacturer’s motors that have a continuous power ranging between 10 and 93kW at their output shafts. The device is compatible with selected frameless and AC main spindle motors. The basic unit of the controller supports the insertion of several modules in its slots.

The firmware of the controller can be installed on a plug-in module, a DSM software module, or in EPROMs. It stores all the parameters of the drive. There should be sufficient load capacity if the product has to be operated outside the ambient temperature range. The device may get damaged in case the load capacity is insufficient. The unit must be installed in a closed housing or a control cabinet according to DIN VDE 0160 specifications. It features a shock resistance of 8.4g for 5ms. The controller can operate at a maximum ambient temperature of 55°C with nominal data derated to 80%. The product can be sent to any address globally with a warranty for one year.
