DKC11.3-200-7-FW

  • Rated 4.6 (22 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911284139
  • Stock: In-Stock, Ships Today
The DKC11.3-200-7-FW drive controller is manufactured by Bosch Rexroth Indramat. This version 3 unit operates with a 200A type current and its firmware is Sold Separately.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 1 Day Rush Repair options are available.

✓ In-Stock!

DKC11.3-200-7-FW

  • Rated 4.6 (22 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911284139
  • Stock: In-Stock, Ships Today
The DKC11.3-200-7-FW drive controller is manufactured by Bosch Rexroth Indramat. This version 3 unit operates with a 200A type current and its firmware is Sold Separately.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 1 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a DKC11.3-200-7-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DKC drive controller series are a part of the digital intelligent ECODRIVE systems from Rexroth. With applications as a servo-drive controller, these drives offer enhanced servomotor performance with improved precision, feedback, and overall control. The DKC11.3-200-7-FW is a version 3 product and is incorporated in the newer and optimized ECODRIVE03 drive system.

The DKC11.3-200-7-FW has a compact structure, featuring a rectangular design. The versatility of this drive across various operations makes it even more effective in motion automation. As a drive controller, the output current and voltage characteristics are important for considering the coupled servo-motor performance. For this drive, the maximum rated current capacity is 200A; this is also the type current. However, the drive can achieve another type of peak current and two separate continuous currents depending on the switching frequency of the drive. At 4kHz switching frequency, the peak current is 100A and the continuous currents are 85A and 100A for the low and high levels respectively; at 8kHz, it has a peak current of 68A and continuous currents of 48A and 68A.

This allows for regulation of the maximum speed and torque of the attached servo motor, by simply adjusting the switching frequency. The ECODRIVE03 can incorporate multiple DKC drives at once, and this determines the type of mains connection for the implemented system. However, the DKC11.3-200-7-FW can be connected for AC input in either the single phase or the three-phase connection. Either way, the input voltage is specified between 200v and 480v AC. Depending on the exact input voltage, the rated charging current can be between 12A and 28A. The name configuration of this drive implies it is of a category 7 voltage class, and that its firmware module needs to be ordered separately from the manufacturer. This product is available from Wake Industrial with a one-year warranty period.

DKC11.3-200-7-FW Documents

  • DKC1132007FW
  • DKC11 3 200 7 FW
  • dkc11.3-200-7-fw

DKC11.3-200-7-FW Technical Specifications

Firmware: Sold Separately
Mounting: Vertical
Product type: Drive controller
Type current: 200 Amps
Voltage category : 7
Input voltage: 380 to 480 Volts AC
Control voltage: 24 Volts DC
UL standard: UL 508 C
Pollution degree: 2
Max ambient temperature: 45 degrees Celsius

Frequently Asked Questions about DKC11.3-200-7-FW


Q: What are spacing requirements for the controller?

A: Bosch recommends providing 150 millimeters spacing on the top side and 80 millimeters spacing on the bottom side of the controller.

Q: Can operators connect the controller directly to the mains supply?

A: As long as the supply voltage matches the input voltage rating, operators can connect the controller directly to the mains supply.

Q: Under what conditions is an autotransformer needed between the controller and the mains supply?

A: An autotransformer is required when the mains voltage exceeds the permitted input voltage range.

Q: What cooling method does the controller use?

A: The controller is equipped witn an internal blower for cooling.

Q: Is the controller suited to outdoor installation?

A: The controller has an IP20 rated housing. Therefore, for outdoor use it must be installed inside a cabinet.

Internal Product Review

  • ‘‘The DKC11.3-200-7-FW is a reliable series 11 drive controller from Bosch Rexroth’s EcoDrive product line.’’
