DKC03.3-008-3-MGP-01VRS Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat DKC03.3-008-3-MGP-01VRS is part of the DKC Drive Controllers series and is designed as an EcoDrive product. This drive controller has a rated current of 8 Amps and a DC-bus nominal voltage of 300 Volts. It weighs 1.8 kilograms and operates with a maximum ambient temperature of 40 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DKC03.3-008-3-MGP-01VRS is a servo drive controller in the DKC Drive Controllers series from Bosch Rexroth Indramat. As part of a modular drive system, it regulates power flow between a supply module and a synchronous or asynchronous motor to support precise velocity and torque control in automated machinery. The unit also combines positioning, monitoring, and safety functions, allowing higher-level controllers to coordinate motion axes in packaging, material handling, and general manufacturing equipment. It is suited to applications that require controlled acceleration, deceleration, and stable running speed during repeated machine cycles. Because regulation is handled inside the controller, the motor can respond quickly to command changes and shifting load conditions.
The controller operates from a DC link of 300 V, which is derived from rectified mains power and sets the available motor voltage range. Under continuous duty, it provides a rated output current of 8 A, while steady line-side demand is limited to a maximum input of 1.3 A. This difference reflects the effect of the DC bus and returned braking energy during deceleration. Internal losses reach 200 W at rated current, so the enclosure needs adequate ventilation to remove heat. Full performance is available at ambient temperatures up to 40 °C, and higher temperatures require output derating to protect the power electronics.
With a mass of 1.8 kg, the unit is easy to mount on compact control panels without placing excessive load on neighboring components. The controller is classified as an EcoDrive, indicating a high-efficiency platform intended for general-purpose multi-interface applications. It uses revision 01, and interface option 03 supports integration with several fieldbus protocols without additional hardware. This allows the controller to fit machines that need communication flexibility across different control architectures. The hardware platform follows design 3, which standardizes connector placement and diagnostic LEDs across compatible units.
Frequently Asked Questions about DKC03.3-008-3-MGP-01VRS:
Q: What is the DC-bus nominal voltage of the DKC03.3-008-3-MGP-01VRS?
A: The DKC03.3-008-3-MGP-01VRS has a DC-bus nominal voltage of 300 V, making it compatible with control systems requiring this voltage level.
Q: What is the rated current for the DKC03.3-008-3-MGP-01VRS drive controller?
A: This model is designed for continuous operation at a rated current of 8 A.
Q: What is the maximum ambient temperature for the DKC03.3-008-3-MGP-01VRS?
A: The DKC03.3-008-3-MGP-01VRS supports operation in environments with ambient temperatures up to 40°C.
Q: How much power does the DKC03.3-008-3-MGP-01VRS dissipate at continuous current?
A: At continuous current, this drive controller dissipates 200 W of power during use.
Q: What design version is the DKC03.3-008-3-MGP-01VRS?
A: This unit is a Design 3 model from the DKC Drive Controllers series.
