DDS03.2-W050-BE32-01-FW

  • Rated 4.5 (23 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911270416
    In-Stock, Ships in 3 Days
  • Unused Original Box Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options

The DDS03.2-W050-BE32-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 50 A rated current, and Digital Servo and Resolver Feedback.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS03.2-W050-BE32-01-FW drive controller from Bosch Rexroth must be connected with a regulated 24VDC voltage from the same manufacturer. The DIAX03 controller is connected to an AC motor through a power cable and a feedback cable. The product may cause bodily injury, property damage or both if the associated safety instructions and user guidelines are not followed. The connections of the components of this device have signal voltages ranging from 5V to 30V. The unit should not be operated if its emergency stop switch is not working. It is not supposed to be pinched or crushed during the handling process. The controller has a power section and a control section.

This drive controller has a software module and one or more plug-in modules along with firmware in its configured state. The product weighs approximately 7.5kg. The device incorporates heat technology as its cooling method. It may be required to use a large control cabinet for the installation of the controller. The software module fitted in the unit depends on the function that the controller is designed to perform. This module incorporates the parameters of both the drive and firmware. The configuration plate of the controller specifies the modules that are inserted in it. The drive controller comes equipped with a one-year warranty period.

The product has a dedicated U5 slot for inserting its software module. The power section of this device has a voltage rating of 300V +/-15%. The controller has a current consumption of 150mA at +/-15V. The unit is ready to receive power if its ready-to-operate Bb contact closes. It is equipped with two analog diagnostic outputs. This product also features a starting lockout mechanism to stop the connected motor from starting accidentally when there is a fault. The device has several diagnostic messages to identify the operational state. The DDS03.2-W050-BE32-01-FW controller can be shipped all over the world.

  • DDS032W050BE3201FW
  • DDS03 2 W050 BE32 01 FW
  • dds03.2-w050-be32-01-fw
  • DDS3.2-W050-BE32-01-FW

DDS03.2-W050-BE32-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo and Resolver Feedback
Rated Current: 50 A
