DDS03.2-W050-BE12-01-FW

Product Description:

The DDS03.2-W050-BE12-01-FW is a drive controller manufactured by Rexroth Indramat. It features a modular concept that enables flexible combination with AC servo and main drives. This creates a compact drive package that uses a single supply unit, and with it, lower energy consumption. It is used in conjunction with MKD, MDD, LAF, and LAR AC motors making it a quick responsive drive ideal for applications in industrial robotics, textile, and food processing machines. It can be connected to any Indramat supply unit with regulated DC 24 V voltage. KDV 1.3, TVM 2.4, and TVM2.1 supply units are compatible with the controller.

Avoid operating the DDS03.2-W050-BE12-01-FW with a TVM 1.2 supply unit since its voltage is not regulated. The drive comes configured to offer functionalities suited for the desired task. It features the hardware and firmware components. A basic unit comprises software modules, plugin modules, firmware, and the drive controller. This DDS controller consists of 3 lines, internal air cooling method, 50A rated current, digital servo and resolver motor feedback, and a SERCOS interface. The firmware of the DDS03.2-W050-BE12-01-FW should be ordered separately. It fixes the functional features of the drive that undergo continuous upgrade without affecting the initial function.

The software module comprises the firmware and drives parameters. It depends on the hardware configurations and functions of the drive. Since it uses heat technology, the DDS03.2-W050-BE12-01-FW should be mounted in a large control cabinet and an optional air conditioning system should be provided. The SERCOS interface integrated into this Rexroth Indramat drive controller enables you to operate the drive with SERCOS compatible controls through fiber optic cable. The permissible operating temperature is 0 to 45 degrees. The DDS03.2-W050-BE12-01-FW can be purchased from Wake Industrial with a one-year warranty period.
