DDS03.2-W030-BA07-01-FW

  • Rated 4.3 (22 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911284684
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS03.2-W030-BA07-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 30 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

DDS03.2-W030-BA07-01-FW

  • Rated 4.3 (22 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911284684
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS03.2-W030-BA07-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 30 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS03.2-W030-BA07-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS03.2-W030-BA07-01-FW is a modular digital controller. It is part of the DDS product line from Bosch Rexroth. The controller is used for motor control in industrial applications. Motors that are compatible with DDS controllers include MKD synchronous motors, MDD synchronous motors, LAR linear inductance motors and LSF synchronous linear motors. Typical applications for servo systems that include DDS controllers include textile, robotics and packaging machines. The continuous rated output of the DDS03.2-W030-BA07-01-FW is 30 Amps. This rating is only valid for controller operation under specified ambient conditions.  Controller operation outside specified conditions is considered improper use. Any equipment damage or personal injury resulting from improper use will be the customer’s responsibility. Improper controller use also voids the product warranty. DDS controller are designed for cold or heat technology.

DDS controllers with cold technology dissipate heat outside the cabinet. DDS controllers with heat technology dissipate heat inside the cabinet. The DDS03.2-W030-BA07-01-FW is designed with heat technology: the cools air enters through an inlet at the bottom of the unit and exits through an outlet at the top. The temperature of air surrounding the controller should be between 0 and 45 degrees Celsius. Smooth air flow is a pre-requisite for proper heat dissipation. Bosch recommends providing at least 40 millimeters of free space in front of the controller and 80 millimeters on the top and bottom sides. The DDS03.2-W030-BA07-01-FW supports both resolver feedback and digital servo feedback. The command communication module on the controller is analog. Housing of the controller is IP20 rated, which implies lack from protection from dust and moisture. Therefore operators can mount the digital controller inside an industrial cabinet for improved environmental protection.

DDS03.2-W030-BA07-01-FW Documents

  • DDS032W030BA0701FW
  • DDS03 2 W030 BA07 01 FW
  • dds03.2-w030-ba07-01-fw
  • DDS3.2-W030-BA07-01-FW

DDS03.2-W030-BA07-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo and Resolver Feedback
Rated Current: 30 A
