DDS03.2-W015-BE32-01-FW

  • Rated 4.5 (17 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911271925
  • Call for Expedited Shipping and Product Condition Options

The DDS03.2-W015-BE32-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 15 A rated current, and Digital Servo and Resolver Feedback.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch DDS03.2-W015-BE32-01-FW is an advanced digital controller. It is part of the DDS series, which is compatible with several motor product lines including LAR linear inductance motors, LAF linear inductance motors, LSF linear synchronous motors and MKD synchronous motors. Typical applications for servo drives comprised of DDS controllers and compatible motors include textiles, handling machines robotics and printing machines. You can connect DDS controller to Bosch DC power supplies that deliver regulated output. The input rating of the drive is 24 Volts DC. DDS controllers cool via natural convection and dissipate heat inside the cabinet. Cool air enters via an inlet at the bottom. Heated air exits via an outlet at the top. The dimensions of the DDS03.2-W015-BE32-01-FW are 355 x 325 x 70 millimeters. Weight of the controller is approximately is 5.5 kilograms.

The recommended free space on the top side of the DDS03.2-W015-BE32-01-FW is 80 millimeters. The recommended free space on the front of the DDS03.2-W015-BE32-01-FW is 40 millimeters. The recommended free space on the bottom side of the DDS03.2-W015-BE32-01-FW is 80 millimeters. Each DDS controller features a command communication module: the module on the DDS03.2-W015-BE32-01-FW supports SERCOS, which is standard for high-speed serial communication over fiber optic cables. The nominal current output of the DDS03.2-W015-BE32-01-FW is 15 Amps. The output is valid if the ambient conditions comply with those specified by Bosch. The DDS03.2-W015-BE32-01-FW controller supports two feedback methods: resolver feedback and digital servo feedback. The controller firmware resides in the software module that occupies Slot U5 on the basic unit. Drive parameters programmed by operators also reside in the software module. Only qualified personnel should install the DS03.2-W015-BE32-01-FW controller and associated equipment.

  • DDS032W015BE3201FW
  • DDS03 2 W015 BE32 01 FW
  • dds03.2-w015-be32-01-fw
  • DDS3.2-W015-BE32-01-FW

DDS03.2-W015-BE32-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo and Resolver Feedback
Rated Current: 15 A
