Product Description

The DDS03.2-W015-BE12-01-FW is a modular drive controller from the Rexroth Indramat Company. Its modular concept provides a flexible way to combine it with AC servo and main drives creating a compact drive package that is more efficient and cost-effective. It can be combined with AC motors such as MKD, MDD, LAF, and LAR. This combination makes it a rapid response drive suitable for applications such as industrial robotics, textile, printing and packaging machines, and handling machines. An Indramat supply unit with DC 24V regulated voltage should be used. Avoid using the TVM 1.2 supply unit since its voltage is not regulated.

The DDS03.2-W015-BE12-01-FW comes already configured to suit the desired function. The controller features are made up of the basic unit, software modules, plugin modules, and firmware. The software module depends on the configuration of the hardware and the functions of the drive. It enables the transfer of the already entered parameters to a new unit. The firmware consist of the functional features of the controller. It is ordered separately allowing you to re-order the same version. It undergoes updates for better performance. The DDS03.2-W015-BE12-01-FW features a DS product group, heat technology cooling method, 15A rated current, SERCOS interface, and digital servo feedback.

Since heat dissipation happens inside the control cabinet, provide a larger control cabinet and an optional air conditioning system. The DDS03.2-W015-BE12-01-FW has a protection category of IP 20 and should be installed in a cabinet that meets IP 10 protection class requirements. The installation elevation is 1000 meters above sea level, relative humidity is 95% without condensation, and the storage/transport temperature is between -30 and 85 degrees. It should be brought to operation in temperature levels between 0 to 45 degrees. The DDS03.2-W015-BE12-01-FW can be purchased from Wake Industrial with a one-year warranty period.
