The DDS03.1-W050-DA01-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 50A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

DDS03.1-W050-DA01-01-FW

  • Rated 4.5 (33 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911270586
  • Stock: In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
The DDS03.1-W050-DA01-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 50A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS03.1-W050-DA01-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS03.1-W050-DA01-01-FW drive controller from Bosch Rexroth acts as an AC digital servo drive. This drive controller must be used only according to the specified guidelines to avoid untoward instances like bodily injury or material damages. The product has a version code of 1 and a series code of 2. The device should be operated only when the safety regulations and instructions for the application it is used for, are adhered to. Any work on the unit must be done only after at least five minutes of turning it OFF. Its power connection can be isolated through an emergency stop circuit for safety against accidental starting up. The drive controller can be sent worldwide with a one-year warranty through our trustworthy delivery partners.

The DDS03.1-W050-DA01-01-FW drive controller has a modular design. The device uses an analog interface as its communications module and incorporates digital servo feedback. It utilizes an IKS3091 service cable for its commissioning. The analog interface supports both incremental and absolute encoder emulators. The interface also features signal outputs and control inputs. The firmware for the unit will have to be ordered as a separate sub-item. The software module is inserted in the U5 slot while the U1 to U4 slots are used to house the plug-in modules.

The faceplate that is removed from the controller during the mounting process must be remounted. The product must be installed within an altitude of 1,000m above sea level. It is protected against penetration of solid objects that have a diameter of more than 50mm. The X1 connector provides the required control electronics. The connection between the drive controller and the supply unit must be done using a bus cable that has a black core present at the bottom. The device is capable of receiving power when its Ready-to-Operate contact closes.

DDS03.1-W050-DA01-01-FW Documents

  • DDS031W050DA0101FW
  • DDS03 1 W050 DA01 01 FW
  • dds03.1-w050-da01-01-fw

DDS03.1-W050-DA01-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 50A
