DDS03.1-W030-RS01-02-FW

  • Rated 4.6 (35 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911264252
    In-Stock, Ships in 3 Days

Current response time:

4 Minutes 18 Seconds

DDS03.1-W030-RS01-02-FW is a Bosch Rexroth drive controller. It is part of the DDS product line. The controller is rated for 30 Amps and supports resolver-based feedback.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

DDS03.1-W030-RS01-02-FW is a drive controller. It is used for control of industrial motors. The controller is manufactured by Bosch Rexroth. DDS controllers work with linear and rotary motors made by Bosch. Specifically, it can be used with motors from the following product lines: MDD, MKD, LAR, and LAF. DDS controllers support either digital servo feedback or resolver-based feedback. The DDS03.1-W030-RS01-02-FW controller supports resolver-based feedback, which enables accurate control of motor speed and position. It is also equipped with a SERCOS communication module. SERCOS is a high-speed serial interface that is widely used for industrial automation applications. Rated output of the DDS03.1-W030-RS01-02-FW controller is 30 Amps. Bosch has designed the unit for air cooling and recommends 0 to 45 degrees Celsius temperature for rated output. Proper spacing around the installed unit helps with dissipation of heat generated during operation. The minimum spacing on the front side of the DDS03.1-W030-RS01-02-FW unit should be 40 millimeters. The minimum spacing on the top and bottom sides of the mounted unit should be 80 millimeters. The controller housing belongs to IP20 protection class. This means that the controller is primarily designed for indoor use. It can be used outdoors when mounted inside a cabinet that provides appropriate environmental ingress protection. Weight of the unit is 5.5 kilograms. Its dimensions are 355 x 325 x 70 millimeters. The modular controller architecture gives operators flexibility in adapting features to application requirements. Firmware for the controller has to be ordered as a separate item. A barcode sticker on the unit allows easy identification. Operators and staff must verify unit specifications at the time of delivery. Any controller found to be damaged at delivery should not be installed.

DDS03.1-W030-RS01-02-FW Technical Specifications

Product type: Drive controller
Cooling: Air cooled
Current rating: 30 Amps
Feedback: Resolver
Input voltage: 24 Volts DC
DC bus voltage: 300 Volts DC
Protection rating: IP20
Communication: SERCOS
Firmware: Separate
Mounting: Vertical

Frequently Asked Questions about DDS03.1-W030-RS01-02-FW


Q: Does the controller support motor feedback?

A: The controller supports resolver-based motor feedback.

Q: What is weight of the controller?

A: The weight of DDS3.1 controllers is approximately 5.5 kilograms.

Q: What are the controller dimensions?

A: The dimensions of DDS3.1 controllers are approximately 355 x 325 x 70 millimeters.

Q: What are spacing requirements?

A: Bosch recommends 80 millimeter spacing on the top and bottom sides and 40 millimeter spacing in front of the unit.

Q: What are the specified ambient temperature limits?

A: Bosch recommends 0 to 45 degrees Celsius temperature for DDS controller operation.

Internal Product Review

  • ‘‘DDS03.1-W030-RS01-02-FW is a high-performance motor controller designed for linear and rotary industiral motors from Bosch Rexroth.’’
