DDS03.1-W030-R

  • Rated 4.7 (26 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911264392
    In-Stock, Ships in 3 Days
  • Call for Expedited Shipping and Product Condition Options

The DDS03.1-W030-R Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 30A rated current, and Resolver Feedback.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Motion control technologies form an important part of most industries that make use of motion drivers. Bosch Rexroth is one of the leading innovators in this field, and also one of the first to enter it. Indramat is its subsidiary firm that specializes in the development and production of state of the art motion control systems such as servo mechanisms, motor drivers, and power supplies.

One of the most impressive drive controller series from the creative professionals of Indramat is the DDS03.1. It is a comprehensive device that offers engineers the facility to control a variety of their motion systems, including AC servos, through a single drive. Not only does this save space but power consumption also. The DDS03.1-W030-R represents a group of products from this series that has a rated operating current of 30A and utilizes internal air flow for cooling. This means that an air flow is maintained inside the control cabinet at all times to ensure the required amount of convective cooling is achieved during operation.

Moreover, this particular DDS03.1-W030-R drive comes equipped with a resolver feedback device for exercising closed loop control. All units come pre-configured by Indramat suited to individual applications of the customer. Since the design is modular, disassembly and troubleshooting is very convenient for engineers if anything should go wrong. A completely configured unit consists of the controller itself, the plugin modules that connect the driver to external components, the supporting software, and firmware programmed by Indramat.

DDS03.1-W030-R is compatible with a diverse range of communication modules, giving consumers the choice of what they prefer. Out of the 4 available options: ANALOGUE, INTERBUS-S, Single axis position control, and SERCOS, engineers get to choose the desired module when ordering. DDS03.1-W030-R by Bosch Rexroth is surely the best of the best. Industrialists looking to optimize their work floors and finances must integrate it in their systems for quick results! The DDS03.1-W030-R can be purchased from Wake Industrial with a one-year warranty period.

  • DDS031W030R
  • DDS03 1 W030 R
  • dds03.1-w030-r

DDS03.1-W030-R Technical Specifications

Cooling: Internal Cooling
95%: Max. Installation elevation with rated data
Rated current : 30 A
Motor feedback : Resolver feedback
Current consumption DC +15V in mA: DC bus voltage
300 V: Maximum peak current
30 A: continuous current
10 Amp: Current consumption DC +24V in mA
500 mA: Protection category
IP20: Max. Permissible relative air humidity

Frequently Asked Questions about DDS03.1-W030-R


Q: 1000 meters

A: The DDS03.1-W030-R proves to be a versatile platform that can be used for a wide variety of drive control systems. It can control motion systems like AC servos and provides comprehensive motion control soultions for various applications.

Q: What is the DDS03.1-W030-R's cooling mechanism?

A: The DDS03.1-W030-R is equipped with the option of internal air flow for cooling. The system maintains internal air flow at all times which is used for constant heat dissipation.

Q: What feedback options are avaialable with this model?

A: This model is equipped with a resolver feedback option that provides precise closed loop control for a variety of drive control applications.

Q: Can this model be customized for specific applications?

A: Yes, the DDS03.1-W030-R can be tailored according to the users' needs and can be enhanced because of its modular design.

Q: Can users chose a specific communication module with this system?

A: Certainly, the DDS03.1-W030-R is provided with the option to chose from a range of communication modules including Interbus-S, Analogue, sercos, and single axis position.

Internal Product Review

  • ‘‘The DDS03.1-W030-R allows efficient control of motion systems and has low power consumption. It can be easily installed because of its space saving arragement.’’
