DDS02.2-W100-BE76-01-FW

  • Rated 4.6 (25 total ratings)
  • MPN: R911276433
  • Stock: In-Stock, Ships 3-5 Days
  • Factory New Pricing Available! Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The DDS02.2-W100-BE76-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 100 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.2-W100-BE76-01-FW

  • Rated 4.6 (25 total ratings)
  • MPN: R911276433
  • Stock: In-Stock, Ships 3-5 Days
  • Factory New Pricing Available! Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The DDS02.2-W100-BE76-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 100 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.2-W100-BE76-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description



The DDS02.2-W100-BE76-01-FW is a drive controller manufactured by Rexroth Indramat. It comes in a modular design that allows it to be combined with AC servo drives to create one compact package that utilizes one supply unit. In connection with MDD, LAR. LSF, LAF, ADF, 1MB, and MKD AC motors, the DDS02.2-W100-BE76-01-FW become a rapid responsive drive. This makes it suitable for applications in industrial robotics, printing and packaging machines, and textile, among others. It can be connected to any Indramat supply unit that has a DC 24V voltage.

The DDS02.2-W100-BE76-01-FW comes configured for the task at and. It features the basic drive controller unit, plugin modules, software modules, and firmware. Falling under the DDS product group, it features 2 lines, internal air cooling method, a rated current of 100A, and a digital servo and resolver feedback. The firmware of this controller is ordered separately. Since it utilizes heat technology for cooling, a large cabinet and an air conditioning system may be needed for optimum airflow. Its software modules consist of the firmware and drive parameters. It can be transferred to another unit in the event of a unit replacement. It comes configured to the function of the drive.

The DDS02.2-W100-BE76-01-FW’s firmware contains the functional features of the drive. It can be upgraded without impacting the functions of the drive. This means you can buy an upgraded version with little to no impact on the DDS02.2-W100-BE76-01-FW. The plugin modules that are found in the drive include the SERCOS interface, Command card, ARCNET coupler card, input/output interface, and others. The interfaces are dependent on the firmware configuration. It features a maximum peak current of 100A and a continuous current of 60A. The DDS02.2-W100-BE76-01-FW can be purchased from Wake Industrial with a one-year warranty period.

DDS02.2-W100-BE76-01-FW Documents

  • DDS022W100BE7601FW
  • DDS02 2 W100 BE76 01 FW
  • dds02.2-w100-be76-01-fw

DDS02.2-W100-BE76-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo and Resolver Feedback
Rated Current: 100 A
