DDS02.2-W100-BE23-01-FW

  • Rated 4.5 (16 total ratings)
  • MPN: R911265341
  • Stock: In-Stock, Ships 3-5 Days
  • Factory New Pricing Available! Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The DDS02.2-W100-BE23-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 100 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.2-W100-BE23-01-FW

  • Rated 4.5 (16 total ratings)
  • MPN: R911265341
  • Stock: In-Stock, Ships 3-5 Days
  • Factory New Pricing Available! Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The DDS02.2-W100-BE23-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 100 A rated current, and Digital Servo and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.2-W100-BE23-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS02.2-W100-BE23-01-FW features a modular concept that allows flexible combination with AC and main servo to form a compact drive package. The package uses a single supply unit making it a cost-effective system. It is to be put into operation in a temperature range between 0 and 45 degrees and stored in temperatures from -30 to 85 degrees. Some of its environmental conditions include a permissible relative humidity of 95%, absolute humidity of 25g/m3, and an installation elevation of 1000 meters above sea level. The protection category is IP 20.

The DDS02.2-W100-BE23-01-FW can be used in conjunction with AC motors such as MDD, MKD, LSF, LAR, and others. This combination makes the drive a rapid response drive which is used in industrial robotics, textile, and packaging machines, among other applications. It can be connected to a supply unit with DC 24V regulated voltage or TVM and KDV supply units. The drive comes configured to suit the desired functions in a basic unit that comprises plugin modules, firmware, software modules, and the drive controller. It features a SERCOS interface, a digital servo and resolver motor feedback, and a 100A rated current.

The cooling method used is the heat technology that dissipates heat within the control cabinet. This requires you to provide a larger cabinet with an air conditioning system to facilitate uninterrupted heat dissipation. The DDS02.2-W100-BE23-01-FW is designed to be mounted in a terminal box that meets the demands of the IP 10 protection category. This is to protect it from penetration by water and intentional access by hand. Ensure that the drive with the highest output is close to the supply unit. It comes with a one-year warranty form Wake Industrial.

DDS02.2-W100-BE23-01-FW Documents

  • DDS022W100BE2301FW
  • DDS02 2 W100 BE23 01 FW
  • dds02.2-w100-be23-01-fw

DDS02.2-W100-BE23-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo and Resolver Feedback
Rated Current: 100 A
