DDS02.2-W050-BE11-02-FW

  • Rated 4.6 (7 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911276823
    In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options

The Bosch Rexroth DDS02.2-W050-BE11-02-FW model provides precise motor control and efficient heat management. The drive controller includes a SERCOS interface communication module and modular adaptability.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth designs and manufactures high-quality devices according to consumer requirements. The products include drive controllers, inverters, amplifier modules, control sections, drive converters, and brake choppers. The DDS02.2-W050-BE11-02-FW model contains a SERCOS interface command communication module and has 50 A of peak current and 50 A of continuous current. The model includes a rapid action control system as well as a control cabinet for heat dissipation externally. In a control cabinet, the DDS02.2 drive controller loses 260 Watts at 40 A constant current. Additional modules for the model can be put into one of five slots. Depending on the usage, each of the U1?U5 slots can carry a different set of modules. The base unit can be adapted to perform a variety of functions with the help of different modules. A command communications module, various plugin modules, and a software module are all inputs to this unit. The DDS02.2 drive controller is designed to work with Rexroth power supplies, but it is not advised for use with unlicensed TVM power supplies. The model weighs 7.5 kilograms and must be operated within a temperature range of 0 to +45 degrees Celsius and a maximum relative humidity of 95 percent to function properly. The model DDS02.2-W050-BE11-02-FW can be deployed at a maximum height of 1000 meters above sea level and has both digital and resolver servo feedback. The module's operating software, as well as the model firmware, must be acquired separately. This module's software and hardware requirements have been pre-configured. With the purchase of this product (DDS02.2-W050-BE11-02-FW), Wake Industrial provides a one-year replacement warranty and can ship it anywhere in the world.

DDS02.2-W050-BE11-02-FW Technical Specifications

Power Supply Unit Rating: 24 V
Operating Temperature Range: 0 to +45 degree centigrade
Maximum Current Rating: 50 A
Communication Module: SERCOS Interface
Motor Feedback: Digital Servo and Resolver Feedback
Weight: 7.5 kg
Protection Rating: IP20
Cooling: Internal Cooling
Storage Temperature Range: (-30 to +85) degree centigrade
Maximum Elevation Height: 1000 MSL

Frequently Asked Questions about DDS02.2-W050-BE11-02-FW


Q: What interface does the DDS02.2-W050-BE11-02-FW drive controller use for command communication?

A: The DDS02.2-W050-BE11-02-FW utilizes a SERCOS interface for efficient and reliable command communication. The interface ensures seamless integration with compatible devices.

Q: How does the DDS02.2-W050-BE11-02-FW model manage heat dissipation?

A: The model includes an internal control cabinet specifically designed for optimal heat dissipation. Effective management of heat increases reliability.

Q: Can the DDS02.2-W050-BE11-02-FW drive controller be customized with additional modules?

A: Yes, the drive controller can host additional modules in its five slots. U1?U5 allows for extensive customization.

Q: What are the environmental operating conditions for the DDS02.2-W050-BE11-02-FW drive controller?

A: It must be operated within a temperature range of 0 to +45 degrees Celsius and a maximum relative humidity of 95% to ensure proper functioning.

Q: Is there any restriction on power supplies for the DDS02.2-W050-BE11-02-FW model?

A: The drive controller is designed for use with Rexroth power supplies. The use of unlicensed TVM power supplies is not recommended.

Internal Product Review

  • ‘‘The DDS02.2-W050-BE11-02-FW model is from the CSH series of drive controllers manufactured by Bosch Rexroth. The model integrates a SERCOS interface for command communication and has a peak and continuous current of 50 A. The drive controller has an internal control cabinet for efficient heat dissipation.’’
