DDS02.2-W015-BE06-01-FW

  • Rated 4.5 (27 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911277995
    In-Stock, Ships 3-5 Days

Current response time:

5 Minutes 33 Seconds

The DDS02.2-W015-BE06-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 15 A rated current, and Digital Servo and Resolver Feedback.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch Rexroth DDS02.2-W015-BE06-01-FW drive controller features an RS  232 interface at its X3 connecting point for a PC or a VT-100 terminal connection. The controller must preferably use the manufacturer’s motor power cables for the AC motor connection. This power cable has a maximum length of 75m. The device has two analog diagnostic outputs that generate drive internal variables for test purposes such as commissioning. The unit must never have a direct connection between its Bb ready-to-operate contact and a contact coil. Its starting lockout does not bring the moving axes of the controller to standstill mode.

This drive controller can function at a maximum temperature of 55°C with reduced data. The product has two control inputs for relay coils with a 1.5W power rating and a 20VDC to 30VDC voltage rating. The device can be connected to either the right or the left of the motor. The motor used with the unit produces both digital servo feedback and resolver feedback. The controller portrays 150mA current consumption at +/-15VDC. The product incorporates a SERCOS interface for command communication. This device portrays IP 20 degree of protection as per EN 60529 standards. The unit is to be transported with the help of shock-absorbing supports if needed.

The controller utilizes an E-DDS 2 electrical connecting accessories kit to simplify its connection process. The product features the motor feedback connection at the X4 connecting point. The device must not use varistors as its protective circuits as this can cause the failure of its components. The unit features a thermistor connection to monitor the temperature of the connected motor. It helps to control the holding brake of the associated motor. This drive controller is available with a year’s Wake Industrial warranty and is transported across the globe to your destination through reputed freight carriers with a worldwide presence.

  • DDS022W015BE0601FW
  • DDS02 2 W015 BE06 01 FW
  • dds02.2-w015-be06-01-fw
  • DDS2.2-W015-BE06-01-FW

DDS02.2-W015-BE06-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo and Resolver Feedback
Rated Current: 15 A
