DDS02.2-A100-BE23-01-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911265332
  • Stock: Call for Quote
The DDS02.2-A100-BE23-01-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a External cooling system with a Rated Current of 100A and Digital Servo Motor Feedback.

DDS02.2-A100-BE23-01-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911265332
  • Stock: Call for Quote
The DDS02.2-A100-BE23-01-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a External cooling system with a Rated Current of 100A and Digital Servo Motor Feedback.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a DDS02.2-A100-BE23-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS02.2-A100-BE23-01-FW is a servodrive from Bosch Rexroth. This digital drive is modular in structure. It is one of the several DDS series of such devices from the manufacturer. The product makes use of the DIAX03 firmware that has to be ordered as a separate sub-item. Many units can be used with a single power supply. The unit has three types of plates for the identification of the software and hardware. The DC bus voltage has a maximum permissible value of 200V. A configured drive controller must be used as a replacement if needed. The servo drive is available with a one-year industrial warranty from Wake Industrial.

The drive must be held at the top and bottom during mounting and hung on to the slackened mounting screws. The screws must be tightened after mounting. The product has a series code of 2 and a version code of 2. The control and power voltages of this device should be switched OFF before a software module is mounted or removed. The unit is intended for use with the MDD, LAR and MKD series of AC motors from the manufacturer. It supports combining AC main and servo drives to form a compact drive package.

The slots of the basic unit of the servo drive are empty. The device is cooled by air circulation outside the control cabinet. The firmware incorporates the functional features of the product. This servo drive has a current rating of 100A. It must be installed only in machines that are meant for commercial use. The unit features an ambient operating temperature range of 0°C and +45°C. It implements resolver feedback and digital servo feedback. The drive can be installed in a small control cabinet. The configuration plate shows the details of the modules used. The DDS02.2-A100-BE23-01-FW can be shipped worldwide.

DDS02.2-A100-BE23-01-FW Documents

  • DDS022A100BE2301FW
  • DDS02 2 A100 BE23 01 FW
  • dds02.2-a100-be23-01-fw

DDS02.2-A100-BE23-01-FW Technical Specifications

Cooling: External
Motor Feedback: Digital Servo
Rated Current: 100A
