DDS02.1-W150-DS04-03-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911270070
The DDS02.1-W150-DS04-03-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a Internal cooling system with a Rated Current of 150A and Digital Servo Motor Feedback.

DDS02.1-W150-DS04-03-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911270070
The DDS02.1-W150-DS04-03-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a Internal cooling system with a Rated Current of 150A and Digital Servo Motor Feedback.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a DDS02.1-W150-DS04-03-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Servo drive controllers are designed to power and monitor the performance of electric servomechanisms. The drives specifically work by receiving a command signal from a control system, amplifying the signal, and then sending the signal to a servo motor to produce motion. The controllers have the extra benefit of providing motor feedback which can be used to detect unwanted motion and ensure the accuracy of a command. The DDS02.1-W150-DS04-03-FW is a digital and modular AC servo control drive unit manufactured by Rexroth, Indramat and comes from its DDS Drive Controller series. This AC servo control drive technology can deliver enhanced motor performance, reliability, and system integration options. Moreover, the modular concept of the drive enables a custom fit that is fully expandable at any time.

The DDS02.1-W150-DS04-03-FW drive controller is equipped with heat technology as a cooling method that features the cooling airflow inside the control cabinet. The rated current for this drive is 150 A and the required supply unit is DC +24 V. The drive controller offers the SERCOS interface as its communication module. The SERCOS interface makes the drive compatible to control via fiber optic cable and offers inputs for evaluating travel range limit switches, reference switches, and sensor inputs. The functional features of the servo drive controller are fixed by the firmware. The firmware must be ordered as a separate item according to the function that the system demands. This Servo Drive is available with a Version of 1 and features Digital Servo Motor Feedback (DSF).

The permissible ambient temperature for this drive ranges between +0 & +45o C with a maximum of +55o C. The DDS02.1-W150-DS04-03-FW drive controller comes with a protection class of IP20 as per DIN VDE 0470-1-1992 and the unit is protected against penetration by a solid extrinsic object with a diameter exceeding 50 mm. The DDS02.1-W150-DS04-03-FW can be shipped to any address worldwide with a one-year warranty period from Wake Industrial.

DDS02.1-W150-DS04-03-FW Documents

  • DDS021W150DS0403FW
  • DDS02 1 W150 DS04 03 FW
  • dds02.1-w150-ds04-03-fw

DDS02.1-W150-DS04-03-FW Technical Specifications

Cooling: Internal
Motor Feedback: Digital Servo
Rated Current: 150A
