DDS02.1-W150-DS03-02-FW

  • Rated 4.5 (13 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911270254
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W150-DS03-02-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 150 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

DDS02.1-W150-DS03-02-FW

  • Rated 4.5 (13 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911270254
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W150-DS03-02-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 150 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-W150-DS03-02-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch DDS02.1-W150-DS03-02-FW is a drive controller. The constituent part of the controller include a controller basic unit, software module, command module, plug in modules, transparent cover and configuration rating plate. The controller is deployed for motor control in industrial applications. The DDS02.1-W150-DS03-02-FW is rated for 150 Amps nominal current output. The nominal output is valid for ambient conditions that comply with manufacturer recommendations. The specified ambient conditions include 0 to 45 degrees Celsius temperature and 0 to 1000 meters altitude. If only the temperature exceeds recommended limits while the altitude is within limits, the output derating reaches a maximum of 20% at 55 degrees Celsius. If only the altitude exceeds recommended limits while the temperature is within limit, the output derating reaches a maximum of 35% at 5000 meters.

When both the altitude and temperature exceed recommended limits, then both load factors must be multiplied. The DDS02.1-W150-DS03-02-FW cools via natural convection. The DDS02.1-W150-DS03-02-FW dissipates heat inside the cabinet. Heat generating devices inside the same cabinet should be appropriately separated to ensure smooth flow of air. The DDS02.1-W150-DS03-02-FW supports digital servo feedback. This allows the drive to receive feedback from a servo motor and to accurately control motor parameters. The command communication module installed on the DDS02.1-W150-DS03-02-FW is SERCOS. Three slots on the DDS02.1-W150-DS03-02-FW are available for plug in modules that can be selected from a wide range of available options. The software module stores both the drive firmware and the operating parameters. The software module can be moved to another drive unit if required. The controller is only allowed to be deployed for permitted applications. The controller should be installed d by trained personnel.

DDS02.1-W150-DS03-02-FW Documents

  • DDS 02.1-W150-DS03-02-FW
  • DDS02-1-W150-DS03-02-FW
  • DDS02.1-W150-DS03-02
  • DDS021-W150-DS03-02-FW
  • DDS021W150DS0302FW
  • DDS2.1-W150-DS03-02-FW
  • DDSO2.1-W150-DS03-02-FW
  • DDS02 1 W150 DS03 02 FW
  • dds02.1-w150-ds03-02-fw

DDS02.1-W150-DS03-02-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 150 A
