Product Description

Indramat has made the best Motion Control available in the industry and they allow complete customization of each drive unit for its application. The DDS series from Rexroth Indramat are compact and highly efficient drive controllers with advanced controlling technology features. The DDS02.1-W150-DA01-01-FW is a digital and modular AC servo control drive unit that comes from Indramat’s DDS series.

A servo drive controller is an electronic amplifier that is used to power and monitors the feedback from servomechanisms. AC servo drive controllers are specifically designed for AC servo motors and provide the added advantage of motor feedback. The drive controllers amplify performance in terms of the desired torque, velocity, and position, as well as feedback gain in AC servo motors and control systems.

The DDS02.1-W150-DA01-01-FW features a modular concept that makes it possible to flexibly combine main drives and AC servo to create one compact drive package which requires one supply unit. The drive controller uses heat technology as a cooling method where the cooling air flows inside the control cabinet. This is why it requires a larger control cabinet with the least amount of mounting and installation efforts. This drive offers a continuous current of 65 A with maximum pick current of 150 A. Generally applicable supply unit for the drive controller is DC +/-15V ea. 200 mA. The firmware fixes the functional features of the drive controller and it must be ordered as a separate item. This designation of the firmware is indicated in the type code as the release status. This Servo Drive is available with a Version of 1 and features Digital Servo Motor Feedback. The DDS02.1-W150-DA01-01-FW offers an IP20 protection class and the maximum permissible ambient temperature for this drive controller is 55^o C. The DDS02.1-W150-DA01-01-FW can be shipped globally to any address with a one-year warranty period from Wake Industrial.
