The DDS02.1-W100-DS01-02-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 100 A rated current, and Digital Servo Feedback.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

DDS02.1-W100-DS01-02-FW is a Digital Servo Drive Controller for AC motors. This model comes from the DDS Series of modular controllers and its manufacturer is Bosch Rexroth Indramat. The DDS02.1-W100-DS01-02-FW is a pre-configured drive and can be considered as a combination of three components; basic drive controller unit, software module, and plugin modules. The basic drive incorporated in this servo drive controller is DDS02.1-W100-D. It is an air-cooled drive controller rated to operate at up to 100 amperes maximum current.

The DDS02.1-W100-DS01-02-FW supports digital servo feedback and comes with one, preinstalled add-on module I.e. DSS01.3-FW in slot # U1 and a software module in slot # U5. The DDS02.1-W100-DS01-02-FW is offered with configuration DS01-02-FW. In this configuration, only the communication and software plug-in module is provided. The remaining slots of this device can be utilized by the end-user as these slots can be loaded with relevant auxiliary or add-on modules. The DSS01.3-FW plug-in module is a SERCOS based interface module that offers SERCOS based control of the digital drive over an optical fiber cable and it also has inputs for sensors. Moreover, the DSS01.3-FW module can also receive inputs from limit switches and reference switches.

The DDS02.1-W100-DS01-02-FW can be deployed in tandem arrangement with other servo drive controllers in applications with multiple drives. You can even supply the required power to multiple DDS drive units from one power supply unit. This drive controller requires an INDRAMAT power supply to operate. You can use any supply unit that can provide controlled DC 24V. All the communication interfaces, motor connection terminals, motor feedback terminals, and other important components of this drive unit are provided on its front-panel for quick and easy access. The DDS02.1-W100-DS01-02-FW can be shipped globally to any address with a one-year warranty period from Wake Industrial.

  • DDS021W100DS0102FW
  • DDS02 1 W100 DS01 02 FW
  • dds02.1-w100-ds01-02-fw

DDS02.1-W100-DS01-02-FW Technical Specifications

Cooling: Internal Cooling
Maximum Elevation Height: 1000 MSL
Power Supply Unit Rating: 24 V
Current Rating : 100 A
DC Bus Voltage : 300 V
DC Bus Voltage Tolerance: 15%
Digital Servo Feedback : Supported
Protection Rating: IP10
Operating Temperature Range: 0 to +45 degree centigrade
Storage Temperature Range: (-30 to +85) degree centigrade

Frequently Asked Questions about DDS02.1-W100-DS01-02-FW


Q: What components are included in the DDS02.1-W100-DS01-02-FW drive controller?

A: The DDS02.1-W100-DS01-02-FW comprises a basic drive controller unit, a software module, and plugin modules. This pre-configured drive is designed for easy integration and flexibility in various industrial applications, with the ability to add additional modules as needed.

Q: How does the DDS02.1-W100-DS01-02-FW support digital servo feedback?

A: The DDS02.1-W100-DS01-02-FW supports digital servo feedback through its preinstalled DSS01.3-FW module in slot U1 and a software module in slot U5. This setup allows for precise control and monitoring of servo motors.

Q: What is the function of the DSS01.3-FW plug-in module in the DDS02.1-W100-DS01-02-FW?

A: The DSS01.3-FW plug-in module in the DDS02.1-W100-DS01-02-FW is a SERCOS interface module for digital drive control via optical fiber and includes inputs for sensors. This module facilitates high-speed, reliable communication and provides additional connectivity for limit and reference switches.

Q: Can the DDS02.1-W100-DS01-02-FW be used in multi-drive applications?

A: Yes, the DDS02.1-W100-DS01-02-FW is suitable for tandem arrangements with other servo drive controllers in multi-drive applications. Its design allows for efficient power distribution from a single power source to multiple drive units.

Q: What are the power supply requirements and accessibility features of the DDS02.1-W100-DS01-02-FW?

A: The DDS02.1-W100-DS01-02-FW requires an INDRAMAT power supply, capable of providing controlled DC 24V. All essential interfaces and terminals are conveniently located on the front panel for easy access, simplifying installation and maintenance processes.
