DDS02.1-W025-RL01-01-FW

  • Rated 4.4 (17 total ratings)
  • MPN: R911266512
  • Stock: In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W025-RL01-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-W025-RL01-01-FW

  • Rated 4.4 (17 total ratings)
  • MPN: R911266512
  • Stock: In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W025-RL01-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Resolver Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-W025-RL01-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth is a worldwide supplier of automation devices used in different industrial sectors. The company offers a broad range of drive converters, VT terminals, and control sections.

The DDS02.1-W025-RL01-01-FW model is specially designed by Bosch to operate the AC synchronous and linear motors with extreme precision and accuracy. The DDS02.1 drive controller constructs a rapid-response drive control system when operated together with the motors and modules specified by the company. For a hassle-free installation, read and understand the instructions and regulations mentioned in the instruction manual. The handling should only be carried out by a highly qualified professional. The main circuit of the controller is operated by the continuous current of 25 A and the dc-link voltage of +24 V and ±15 V is supplied by the respective power supply module. The controller acts as a single-axis positioning module and the DLC01.1 single-axis positioning module is placed in the U1 slot of the basic unit. U2 slot of the controller is equipped with a DEA04.1 input/output module for exchanging binary signals with the PLC. U3 and U4 slots of the controller are not equipped with any plug-in modules and a cover is placed over them.

The model DDS02.1-W025-RL01-01-FW and its firmware module should be ordered according to the required functions. Resolve motor feedback is placed for relative indirect position detection. The controller must be mounted under the surrounding temperature range of 0 to +45 degree Celsius and the module uses external air to control its ambient temperature. The drive enclosure is secured under the IP20 protection category. The ideal storage temperature for this controller is -30 to +85 degree Celsius. You can order this controller (DDS02.1-W025-RL01-01-FW) directly by visiting Wake Industrial.

DDS02.1-W025-RL01-01-FW Documents

  • DDS 02.1-W025-RL01-01-FW
  • DDS02-1-W025-RL01-01-FW
  • DDS02.1-W025-RL01-01
  • DDS021-W025-RL01-01-FW
  • DDS021W025RL0101FW
  • DDS2.1-W025-RL01-01-FW
  • DDSO2.1-W025-RL01-01-FW
  • DDS02 1 W025 RL01 01 FW
  • dds02.1-w025-rl01-01-fw

DDS02.1-W025-RL01-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Resolver Feedback
Rated Current: 25 A
