DDS02.1-W025-DS24-02

  • Rated 4.6 (24 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911266242
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W025-DS24-02 Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

DDS02.1-W025-DS24-02

  • Rated 4.6 (24 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911266242
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W025-DS24-02 Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a DDS02.1-W025-DS24-02 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Rexroth DDS02.1-W025-DS24-02 is a DDS drive controller. It is designed for installation in control cabinet of machines which are intended for commercial use. Typical applications for the DDS02.1-W025-DS24-02 include use in machine tools, textile, printing and packaging machinery as well as robotics and handling machines. As making contact with equipment containing components that carry voltages in excess of 50 Volts can be dangerous for personnel, it is recommended that only trained and qualified personnel be allowed to perform installation and maintenance of the drive controller. Safety regulations and guidelines should be followed at all times when working on the drive controller. While selecting the motor-controller combination, it is necessary to make sure the motor feedback data type codes of motor are in agreement with the drive controller.

The DC bus voltage for the DDS02.1-W025-DS24-02 is 300 Volts. Rated peak current and continuous current for the drive controller is constant 25 Amps. Current consumption of the basic unit of the drive at DC +/-15 V is 150 mA while it is 200 mA for DC +24 V. The energy loss in the control cabinet of this controller is 170 W. The motor features a digital servo feedback system with negligible current consumption at DC +/-15 V but 40 mA of current consumption at DC +24 V. It has a SERCOS interface of communication module and a firmware version 02 present. In addition the DDS02 drive controller has accessories kits like E..-DDS 2, connector kit S..-DDS 2, electrical and mechanical kits. The DDS02.1-W025-DS24-02 weighs approximately 7.5 kilograms and has protection category of IP20 rating as per EN60529 / IEC529. The permissible ambient temperature range is 0 to 45 degrees Celsius.

DDS02.1-W025-DS24-02 Documents

  • DDS021W025DS2402
  • DDS02 1 W025 DS24 02
  • dds02.1-w025-ds24-02
  • DDS2.1-W025-DS24-02

DDS02.1-W025-DS24-02 Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 25 A
