Product Description

The DDS02.1-W025-DS03-02-FW drive controller encompasses an incremental position interface in its second slot. This interface in the Bosch Rexroth controller helps to transmit square wave signals to evaluate an external scale. This scale is mounted directly on the moving machine component. The product has no plug-in modules in its third and fourth slots. The device should never be used with an unregulated power supply. This unit must always be properly and correctly assembled, installed, transported and stored for safe and optimum operation. Its firmware has to be procured as a separate subitem. This firmware helps in fixing the functions of the controller and has a separate configuration rating plate.

The controller installation must be done only in commercial machinery. The product is to be operated only if the application adheres to the national EMC directives. The drive is an apt choice for use in handling machines, robotics, and machine tools. The device should not be operated even for a brief while without a permanent connection of the associated earth wire to all its electrical components. The unit is intended to be worked on only after ten minutes of switching it OFF so that its capacitors get discharged fully. This DDS02.1-W025-DS03-02-FW controller is backed up by a warranty for one year.

The product might start moving dangerously at any point of time during operation because of incorrect use of its components. The device should have an isolated power connection by means of an emergency stop circuit to avoid unintentional start-up. The unit must not be used near a radio, remote control, and high-frequency equipment. It comes configured in terms of the specified function. The firmware and drive parameters are stored in the software module. The signal voltage for the drive ranges from 5V to 30V. This controller is transported through reputed freight carriers to any part of the globe.
