DDS02.1-W025-DS03-01

  • Rated 4.5 (13 total ratings)
  • MPN: R911261972
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W025-DS03-01 Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-W025-DS03-01

  • Rated 4.5 (13 total ratings)
  • MPN: R911261972
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W025-DS03-01 Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a DDS02.1-W025-DS03-01 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch Rexroth DDS02.1-W025-DS03-01 drive controller has a ground connection for the motor at its top. The product makes use of two DC bus rails for the DC bus connections. The device is equipped with a fault reset key and a H1 status display. This LED status display highlights the error and warning messages. The unit comprises two analog diagnostic outputs that are capable of generating drive-internal variables for test purposes such as commissioning. These outputs have an output voltage of 10VDC and a current load capacity of 4mA. Its plug-in components have to be transported or stored in special packaging to avoid getting damaged.

The drive controller is ready to receive power if its Bb ready to operate contact closes. This contact closes when its monitoring functions signal a ready state and the control voltage is ON. The product supports a starting lockout mechanism to avoid the connected motor from accidentally starting up in case of a fault. The lockout can be activated by applying a 20VDC to 30VDC voltage between the AS+ as well as AS- input terminals. The device must be used only with a motor that incorporates digital servo feedback. The feedback is connected to the X4 connector of the unit.

The product must use the manufacturer’s feedback cables for connecting the controller and the feedback. This cable should have a maximum length of 75m. The controller is intended to operate between an ambient temperature range of 0°C and 45°C with rated data. The device is associated with a function ID version code of 01. The unit is cooled by means of airflow inside the control cabinet. It may be required to use a large control cabinet for the installation. The parameters of the drive are stored in its software module. We can ship this drive controller with a year’s Wake Industrial warranty to the destination of your choice.

DDS02.1-W025-DS03-01 Documents

  • DDS021W025DS0301
  • DDS02 1 W025 DS03 01
  • dds02.1-w025-ds03-01

DDS02.1-W025-DS03-01 Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 25 A
