DDS02.1-W025-DL40-01-FW

  • Rated 4.4 (15 total ratings)
  • MPN: R911272819
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W025-DL40-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-W025-DL40-01-FW

  • Rated 4.4 (15 total ratings)
  • MPN: R911272819
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W025-DL40-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 25 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-W025-DL40-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Rexroth DDS02.1-W025-DL40-01-FW is a drive controller. It is a rapid-response drive used to adjust input power to a motor. They use feedback from the servo motor to control the positions and velocities of machine parts. The drive controller is designed for installation in machines that are intended for commercial uses. Some examples of applications of the DDS02.1-W025-DL40-01-FW drive controller are conveyor belts and spindle drive systems, among others.  The drive controller can be connected to supply units with a regulated DC 24V voltage. The start-up of equipment with a drive controller is only permitted once it is sure that the machine in which the products are installed complies with EC directive 89/392/EWG (machine directives). Avoid touching the electrical connecting points of a component while it is switched on and in operation, and cover live parts properly before switching the equipment on so that no contact is possible. The drive components monitoring devices make malfunctions in these connected drives almost impossible.

The maximum installation elevation for the DDS02.1-W025-DL40-01-FW is 1000m, and operation should be at an ambient temperature range of 0 to 45 degrees Celsius. The permissible energy loss in the control cabinet for the drive controller is 260W. The cooling system is an air-cooling model with external air cooling the control cabinet. The rated current is 25 Amperes, and the motor feedback is a digital servo feedback mechanism. The mass of the drive controller is approximately 7.5 kilograms. The communications module for the DDS02.1-W025-DL40-01-FW is single-axis position control and the operational firmware, which are available to be ordered separately. It features an IP20 protection category, per EN 60529 = DIN VDE 0470-1-1992 (IEC 529-1989).

DDS02.1-W025-DL40-01-FW Documents

  • DDS021W025DL4001FW
  • DDS02 1 W025 DL40 01 FW
  • dds02.1-w025-dl40-01-fw

DDS02.1-W025-DL40-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 25 A
