Product Description

The DDS02.1-W025-DL02-01-FW is a very powerful and sophisticated industrial drive controller designed by Rexroth Indramat to provide industrial operators with an accurate means of synchronous and induction motor control in the industrial servo system. This drive controller is designed according to the international quality standards; it features a housing unit that meets the IP20 protection class and is specially structured to allow for the direct installation of the controller into the industrial servo system. Although the DDS02.1-W025-DL02-01-FW industrial drive controller is designed to be perfectly safe for industrial operations, operators should ensure it is not operated with the right configuration parameters and wiring connections; this is important to prevent dangerous movement in the industrial servo system. The housing of the DDS02.1-W025-DL02-01-FW industrial drive controller is inscribed with special safety signs and symbols designed to warn industrial operators of the dangers associated with the wrong handling of specific parts of the controller.

The DDS02.1-W025-DL02-01-FW industrial drive controller requires an input current of about 25 amperes for optimum operation. The temperature regulated its internal temperature via forced ventilation; this temperature regulation system uses an external heatsink and air blower to conduct the heat generated in the housing of this controller outside the control cabinet, allowing the industrial operator to install numerous controllers into the small cabinet without the risk of overheating. The approximate heat energy dissipated away from this drive controller under normal operating conditions is about 170 watts.

The DDS02.1-W025-DL02-01-FW industrial drive controller is supplied with a type label that industrial operators can use to verify the properties of the controller as soon as it is delivered. This controller generates a leakage current of about 3.5 milliamperes during operation, to prevent electrical accidents, this controller and all accessories connected to it should be properly grounded before operation.
