DDS02.1-W015-RS03-03-FW

  • Rated 4.6 (14 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911271167
    In-Stock, Ships 3-5 Days

Current response time:

6 Minutes 22 Seconds

The DDS02.1-W015-RS03-03-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 15 A rated current, and Resolver Feedback.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth uses world-leading technologies to manufacture its mechanical and electrical products like drive controllers, frequency converters, and industrial PCs.

The DDS02.1-W015-RS03-03-FW model is designed to develop a quick-response motion control system for various industrial sectors. The DDS02.1 drive controller can be used in several commercial and industrial sectors such as manufacturing industries, packaging industries, automation industries, and textile industries. The input voltage required by the controller is 24 VDC which assists in making a connection with the main supply unit. The controller is secured under the IP20 protection category that provides resistance against 12.5 mm solid particles but will not provide any protection against liquid. The DDS02.1 drive controller is equipped with a DSS01.3-FW SERCOS interface for developing real-time communication with the controller and the attached I/O devices. Slot U2 of the drive controller is equipped with a DEF01.1 incremental position interface that supports the transmission of square wave signals. The position and speed of the synchronous and linear motors are controlled by resolver feedback. Slot U3 – U4 is empty and the controller firmware is installed in the U5 slot of the controller. The operating parameters and the software are stored in the U5 slot of the controller.

The model DDS02.1-W015-RS03-03-FW is designed to operate at the rated current of 15 A, and it dissipates the rated power of 150 – 500 mA. As per the DDS user manual, the drive controller must be mounted under the ambient temperature range of 0 to +45 degree Celsius between the relative humidity of 95%. Only a highly trained person is allowed to operate and handle this drive controller. The DDS02.1 drive controller (DDS02.1-W015-RS03-03-FW) can be ordered directly from Wake Industrial and get it along with a one-year replacement warranty.

  • DDS021W015RS0303FW
  • DDS02 1 W015 RS03 03 FW
  • dds02.1-w015-rs03-03-fw
  • DDS2.1-W015-RS03-03-FW

DDS02.1-W015-RS03-03-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Resolver Feedback
Rated Current: 15 A
