DDS02.1-W015-DL01-01-FW

  • Rated 4.4 (37 total ratings)
  • MPN: R911266561
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W015-DL01-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 15 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-W015-DL01-01-FW

  • Rated 4.4 (37 total ratings)
  • MPN: R911266561
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-W015-DL01-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with Internal Cooling, 15 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-W015-DL01-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth manufactures reliable automation products. The company offers a wide range of drive controllers, frequency converters, and brake resistors. The company is committed to deliver quality equipment.

The DDS02.1-W015-DL01-01-FW model is manufactured and developed by one of the leading automation equipment manufacturers (Rexroth Indramat). The model is a digital intelligent drive controller designed to control the function and parameters of the motor. The DDS02.1 drive controller should only be installed vertically along with the power supply module. The controller comes in a modular design and it must be operated according to the conditions specified in the user manual. The DDS drive controller uses air from inside the control cabinet to maintain the ambient temperature of the housing. The operational software and the drive parameters are stored in the firmware module (DSM02.1) and if the unit needs to be replaced the already entered parameters can be shifted to the new unit. Slot 1 of the drive controller is equipped with a DLC01.1 single-axis positioning module. The digital servo feedback should be connected to the X4 port of the controller. The DDS02.1 drive controller dissipated the 150 – 500 mA of power under constant working conditions. The DDS controller can bear the maximum temperature of +55 degree Celsius.

The model DDS02.1-W015-DL01-01-FW has a rated current requirement of 15 A. Slot 2 of the drive controller is equipped with DEA04.1 input/output module and provides 15 inputs and 16 outputs to exchange binary signals with a PLC. Slots 3 – 4 of the controller are empty and slot 5 is designated for the firmware module. The allowable temperature range for the DSS02.1 module is 0 to +45 degree Celsius, without reduction in drive data. Order this controller by visiting Wake Industrial.

DDS02.1-W015-DL01-01-FW Documents

  • DDS021W015DL0101FW
  • DDS02 1 W015 DL01 01 FW
  • dds02.1-w015-dl01-01-fw

DDS02.1-W015-DL01-01-FW Technical Specifications

Cooling: Internal Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 15 A
