DDS02.1-A150-DS01-02-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911271745
  • Stock: Call for Quote
The DDS02.1-A150-DS01-02-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a External cooling system with a Rated Current of 150A and Digital Servo Motor Feedback.

DDS02.1-A150-DS01-02-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911271745
  • Stock: Call for Quote
The DDS02.1-A150-DS01-02-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a External cooling system with a Rated Current of 150A and Digital Servo Motor Feedback.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a DDS02.1-A150-DS01-02-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS02.1-A150-DS01-02-FW drive controller belongs to the DIAX02 product group of controllers. The Bosch Rexroth product encompasses a modular concept. This supports a flexible combination of AC servo and main drives as a single space-saving drive package that needs only one supply unit. The device has a series code of 2 and a version code of 1. It operates along with certain motors from the manufacturer as a rapid-response drive. The device must incorporate only those spare parts that are approved by the manufacturer. The drive controller has a basic unit, software modules, plugin modules and firmware in its configured state.

The product is equipped with a firmware configuration rating plate and a hardware configuration plate. The device must be mounted inside a control cabinet. It supports connection with the manufacturer’s supply units that render a regulated 24VDC voltage. The unit must be assembled, installed, stored and transported properly by qualified personnel for safe and optimal operation. The drive controller is cooled during operation by means of circulating air inside the control cabinet. The product features a protection rating of IP 10 according to DIN 40 050 specifications.

The device must be installed only in machines that are intended to be used commercially. The product must be started only if the machine in which it is housed complies with 89/392/EWG EC directive. The drive controller should not be allowed to function unless there is a permanent connection of the earth wire to each electrical component. Its power section features a DC bus voltage rating of 300 +/-15% VDC. The overload factor helps in determining the 105A continuous current rating of the unit. The product can operate at a maximum temperature of 55°C with derated data. The drive controller can be sent to any address of your choice across the world with a one-year warranty.

DDS02.1-A150-DS01-02-FW Documents

  • DDS021A150DS0102FW
  • DDS02 1 A150 DS01 02 FW
  • dds02.1-a150-ds01-02-fw

DDS02.1-A150-DS01-02-FW Technical Specifications

Cooling: External
Motor Feedback: Digital Servo
Rated Current: 150A
