DDS02.1-A150-DL04-01-FW

  • Rated 4.4 (27 total ratings)
  • MPN: R911267781
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A150-DL04-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 150 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-A150-DL04-01-FW

  • Rated 4.4 (27 total ratings)
  • MPN: R911267781
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A150-DL04-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 150 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-A150-DL04-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS02.1-A150-DL04-01-FW is a DDS series drive controller. It is developed by Bosch Rexroth for motor control applications. As per the product type code, the function ID for the controller is 04 and the function ID version is 01. The firmware for the DDS02.1-A150-DL04-  01-FW has to be ordered separately. In addition to the drive parameters, the software module also stores the drive firmware. If a DDS controller starts to malfunction, the software module can be removed and installed on a replacement controller. This leads to a significant reduction in system downtime leading to minimal impact on industrial productivity. The controller firmware is being continuously updated to support new and improved features. Each DDS02.1-A150- DL04-01-FW controller comes with a configuration rating plate which lists type designations for the drive controller, the basic unit, the software module and the plug in modules.

The type designations listed on the rating plate can be used to determine the slots which are designated for the components on the controller basic unit. If a controller breaks down, the information on the rating pate can be used to identify replacement parts. The rating plate should be checked prior to commissioning to ensure that the modules are in their designated slots. Rated output current of the DDS02.1-A150-DL04-01-FW is 150 Amps. The controller supports digital servo feedback. A single-axis position control module is installed on the controller. The controller used air from inside the control cabinet for cooling. The working temperature range for the DDS02.1-A150-DL04-01-FW is 0 to 45 degrees Celsius. The output of the controller derates between 45 and 55 degrees Celsius. The output also derates at altitudes that exceed 1000 meters.

DDS02.1-A150-DL04-01-FW Documents

  • DDS021A150DL0401FW
  • DDS02 1 A150 DL04 01 FW
  • dds02.1-a150-dl04-01-fw

DDS02.1-A150-DL04-01-FW Technical Specifications

Cooling: External Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 150 A
