DDS02.1-A100-DS22-00/S002

  • Rated 4.4 (10 total ratings)
  • MPN: R911258326
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A100-DS22-00/S002 Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 100 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-A100-DS22-00/S002

  • Rated 4.4 (10 total ratings)
  • MPN: R911258326
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A100-DS22-00/S002 Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 100 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-A100-DS22-00/S002 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS02.1-A100-DS22-00/S002 digital drive system is a modular device designed by the Rexroth Indramat to serve as a power drive for servo motors. It is coded with programs that control given hardware and allows industrial motors to operate in a broad range for industrial production systems. It functions as a reliable control system for various models of industrial servo motors, with which it provides highly controlled speed for applications in machine tools, plant machines, and so on. It is designed to be inserted or placed in an external control cabinet, which is designed according to the IP 54 to prevent the ingression of solid extrinsic materials and liquid substances.

The DDS02.1-A100-DS22-00/S002 motor drive is an electrical drive system that uses digital servo feedback, which transmits feedback responses with a high transmission rate for controlling the speed, torque, and direction of an electric motor connected to it. It also uses a SERCOS interface, a real-time serial communication system that sets a digital interface with servo motors in connection with it for rapid, effective response. It has thermal overload relays, which serve as protection against overload in the drive system.

The DDS02.1-A100-DS22-00/S002  drive system has a cooling mechanism, which operates to reduce the internally generated heat. The electrical section of the blower is protected within the control cabinet. The power section and the blower impeller are outside the control cabinet. The heat sink also, which transfers the heat generated by the operation of this electronic servo drive system into a fluid medium, which is dissipated away from the device as a means of temperature regulation mechanism, is outside the control cabinet. It has a power dissipation of 97 watts and a rated current of 100 Amperes.

DDS02.1-A100-DS22-00/S002 Documents

  • DDS021A100DS2200/S002
  • DDS02 1 A100 DS22 00/S002
  • dds02.1-a100-ds22-00/s002

DDS02.1-A100-DS22-00/S002 Technical Specifications

Cooling: External Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 100 A
