DDS02.1-A100-DS03-02-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911279144
  • Stock: In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A100-DS03-02-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a External cooling system with a Rated Current of 100A and Digital Servo Motor Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-A100-DS03-02-FW

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911279144
  • Stock: In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A100-DS03-02-FW Servo Drive is manufactured by Rexroth Indramat Bosch. This drive has a External cooling system with a Rated Current of 100A and Digital Servo Motor Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a DDS02.1-A100-DS03-02-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS02.1-A100-DS03-02-FW is manufactured by Bosch Rexroth Indramat and is a DDS series drive controller version 1 and series 2. This AC servo control drive offers a cooling style of air, control cab, internal air, and has an output of 100 A rated current. The communications module for this AC servo control drive unit is the SERCOS interface and the motor feedback is the digital servo feedback type. The unit further features a function ID of 03 and a function ID version of 02.

The DDS02.1-A100-DS03-02-FW drive controller is a dual type of unit that can be considered both modular and digital. This allows the end user to stack these drives with multiple other drives, and in this configuration,  they can run off of one power supply or multiple power supplies. The drive can be controlled via SERCOS or can even be controlled with analog input. You can also utilize control cards such as a single axis DLC control card to control the DDS02.1-A100-DS03-02-FW drive controller. One of the reasons these drives are chosen by many is because they are very adaptable and user-friendly.

The DDS02.1-A100-DS03-02-FW drive controller device is almost identical to a number of other devices from the DDS series. You will find that their external appearances are exactly the same in a lot of cases for many of the devices in this series. However, when it comes to power ranges you will see differences. You can also see differences in the firmware used across different drive controllers in the DDS 2.1 series and the DDS 2.2 series. You will find that this specific device and other DDS 2.1 devices will use the Diax02 firmware. This product can be purchased from Wake Industrial with a one-year warranty period.



DDS02.1-A100-DS03-02-FW Documents

  • DDS021A100DS0302FW
  • DDS02 1 A100 DS03 02 FW
  • dds02.1-a100-ds03-02-fw

DDS02.1-A100-DS03-02-FW Technical Specifications

Cooling: External
Motor Feedback: Digital Servo
Rated Current: 100A
