DDS02.1-A100-DS01-02-FW

  • Rated 4.3 (8 total ratings)
  • MPN: R911269398
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A100-DS01-02-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 100 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-A100-DS01-02-FW

  • Rated 4.3 (8 total ratings)
  • MPN: R911269398
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A100-DS01-02-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 100 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-A100-DS01-02-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The DDS02.1-A100-DS01-02-FW is a Bosch Rexroth Indramat DDS drive controller. It uses a cold technology cooling system and weighs around 11 kg. Except for TVM 1.2 units, DDS drive controllers from Rexroth Indramat are compatible with all the company's regulated DC 24V supply units. The basic unit of the DDS02.1-A100-DS01-02-FW is adaptable to different functions through the use of various modules.

The DDS02.1-A100-DS01-02-FW has the advantage of dissipating considerable heat away from the control cabinet. As a result, it is well suited for installation in small cabinets or housings. Additionally, it is adaptable to various applications and compatible with a variety of software modules, depending on the functions required. The function ID of the DDS02.1-A100-DS01-02-FW is 01, and the function ID version is 02. This model operates appropriately in a temperature range of 0 to 45 degrees Celsius. When operated at reduced data, its maximum allowable temperature is 55 degrees Celsius.

It has a rated current of 100 A and leverages a digital servo motor feedback mechanism. In addition, it communicates with the rest of the system through a Sercos Interface. The control cabinet of this AC drive controller consumes 97 watts of energy. Additionally, it features a DC bus voltage of 300 Volts and a +/- 15% tolerance. DDS drive controllers can be assembled up to a maximum height of 1000 meters. As the assembly height of these drives exceeds the specified height, their power rating and other equipment requirements decrease. At all times, the DDS02.1-A100-DS01-02-FW must be handled by trained and qualified personnel.

DDS02.1-A100-DS01-02-FW Documents

  • DDS021A100DS0102FW
  • DDS02 1 A100 DS01 02 FW
  • dds02.1-a100-ds01-02-fw

DDS02.1-A100-DS01-02-FW Technical Specifications

Cooling: External Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 100 A
