DDS02.1-A050-DS24-04-FW

  • Rated 4.5 (32 total ratings)
  • MPN: R911288512
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A050-DS24-04-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 50 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-A050-DS24-04-FW

  • Rated 4.5 (32 total ratings)
  • MPN: R911288512
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A050-DS24-04-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 50 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a DDS02.1-A050-DS24-04-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Rexroth Indramat's DDS02.1-A050-DS24-04-FW digital AC drive controller is part of the DDS Series 2 product line. This unit is specifically designed for the effective control of servo motors. It weighs approximately 11 kg, features a modular design, and can be used for a variety of drive applications. The DDS02.1-A050-DS24-04-FW is housed in an IP 10-rated air control cabinet and utilizes a cold cooling technology that draws air from outside the cabinet and exhausts all heat outside the cabinet. This unit is pre-configured and comes with all of the required software and hardware. It features a 50-amp rated current and a digital servo motor feedback mechanism. Additionally, the DDS02.1-A050-DS24-04 communicates via a SERCOS interface.

The firmware for the DDS02.1-A050-DS24-04-FW is purchased separately from the rest of the model. If this unit needs to be replaced, its software module ensures that operating parameters can be transferred to a different drive control unit. The DDS02.1-A050-DS24-04-FW’s function I.D is 24 and the function I.D version is 03. This model is able to work well in an ambient air temperature of between 0 and 45 degrees Celsius. Operating the product at a reduced data results in a maximum allowable temperature of 55 degrees Celsius.

The permissible assembly height of the DDS02.1-A050-DS24-04-FW drive controller is 1000 meters high, and the power rating and other equipment requirements decrease above the specified height. Additionally, its design and structural composition comply with the IP 20 material protection class, according to EN 60529. The energy loss of this AC drive controller's control cabinet is rated at 54 watts. Its DC bus voltage is 300 Volts with a tolerance of 15 %.

DDS02.1-A050-DS24-04-FW Documents

  • DDS021A050DS2404FW
  • DDS02 1 A050 DS24 04 FW
  • dds02.1-a050-ds24-04-fw

DDS02.1-A050-DS24-04-FW Technical Specifications

Cooling: External Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 50 A
