DDS02.1-A050-DS04-01

  • Rated 4.8 (5 total ratings)
  • MPN: R911267822
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A050-DS04-01 Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 50 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

DDS02.1-A050-DS04-01

  • Rated 4.8 (5 total ratings)
  • MPN: R911267822
  • Call for Expedited Shipping and Product Condition Options
The DDS02.1-A050-DS04-01 Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 50 A rated current, and Digital Servo Feedback.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a DDS02.1-A050-DS04-01 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Designed by Rexroth Indramat, the DDS02.1-A050-DS04-01 is an intelligent digital drive controller that uses cold cooling technology. This drive controller has a current rating of 50 Amperes. It features a Digital Servo feedback mechanism, as well as a SERCOS interface command module. The DDS02.1-A050-DS04-01 has the function code of 04. For a DDS unit to be completely assembled, it must have the following components: a software module, a command interface, and optional auxiliary plugin modules. In its compatible software module, the drive parameters of this unit are included.

The DDS02.1-A050-DS04-01 has an IP 20 protection category, a maximum permissible absolute air humidity of 25 g/m3, and a maximum permissible relative humidity of 95 percent. The permissible ambient temperature of this Rexroth drive controller with 100 percent rated data is between 0 – 45 degrees C. It also has a temperature range of -30 to 85 degrees Celsius for transport and storage. The DC bus voltage of the DDS02.1-A050-DS04-01 is 300 V (+/- 15 %).

It has a maximum peak current of 50 Amperes for a continuous current of 50 Amperes. The digital servo motor feedback on the DDS02.1-A050-DS03-01 has a current consumption of 40 mA at DC +24 Volts. Like other DDS drive controllers, this model supports connection to supply units manufactured by Rexroth Indramat with a regulated voltage of DC 24 V. The SERCOS interface plugin module on the DDS02.1-A050-DS04-01 offers inputs for evaluating reference switches, sensor inputs, and travel range limit switches. Also, the storage environment of this drive controller must be dry, shock-free, and dust-free. During transportation, shock-damping supports can be used if necessary. Its cable length has a maximum value of 75 meters, provided Rexroth Indramat manufactures them.

DDS02.1-A050-DS04-01 Documents

  • DDS021A050DS0401
  • DDS02 1 A050 DS04 01
  • dds02.1-a050-ds04-01

DDS02.1-A050-DS04-01 Technical Specifications

Cooling: External Cooling
Motor Feedback: Digital Servo Feedback
Rated Current: 50 A
