DDC01.2-N100A-DA02-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911271462
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
3 Minutes
45 Seconds
The Bosch Rexroth Indramat DDC01.2-N100A-DA02-01-FW is part of the DDC Digital Intelligent Servo Drives series and weighs 22 kilograms. This drive features a rated current of 100 Amps, operates with a continuous mechanical load of 6 kW, and uses standard cooling. It provides IP65 protection and supports digital servo feedback with an analog interface command module.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDC01.2-N100A-DA02-01-FW digital intelligent servo drive is produced by Bosch Rexroth Indramat for the DDC Digital Intelligent Servo Drives series. Classified as a digital intelligent servo drive, it integrates power conversion and motor feedback processing for closed-loop servo axes in plant automation. It regulates velocity, position, and torque for motors used on pick-and-place gantries, conveyors, and machine-tool feed axes, replacing discrete analog amplifiers with integrated digital control. This arrangement supports precise axis control in automated machinery.
At the power stage, the drive delivers a rated phase current of 100 A, matching medium-frame synchronous motors. Its inverter can sustain a continuous mechanical output of 6 kW, while short acceleration profiles permit a peak mechanical demand of 17 kW. Between these two limits, a short-term mechanical output of 12 kW is available for moderate indexing moves. To support these operating conditions, the mains connection must provide up to 18 kVA of apparent power. The housing is sealed to IP65, allowing cabinet-free mounting near the actuator while protecting the electronics from dust and directed water jets. Thermal energy is removed through integrated forced-air cooling.
The internal resistor network dissipates braking energy, handling 0.25 kW continuously and rising to 20 kW during brief decelerations. Regenerated energy is limited to 10 kWs so the DC link voltage stays within safe operating limits. Reliable operation is maintained up to +55 °C ambient temperature, 25 g/m³ absolute humidity, and 1000 m installation height. Control signals enter through an analog interface command module, and rotor position is returned through digital servo feedback for high-resolution control loops. Noise emission is standard for 100 A to 200 A units. Firmware for this unit is supplied separately and must be ordered from the manufacturer to match the intended application. The unit uses function code 02 and version 01, with Series 1 hardware, drive version 2, and a mass of 22 kg.
Frequently Asked Questions about DDC01.2-N100A-DA02-01-FW:
Q: What is the rated current output of the DDC01.2-N100A-DA02-01-FW servo drive?
A: The DDC01.2-N100A-DA02-01-FW delivers a rated current of 100 A for continuous operation.
Q: What protection rating does the DDC01.2-N100A-DA02-01-FW feature?
A: This model is protected to an IP65 category, offering complete protection against dust and strong water jets.
Q: What type of motor feedback does the DDC01.2-N100A-DA02-01-FW utilize?
A: Digital Servo Feedback is used for precise motor feedback on the DDC01.2-N100A-DA02-01-FW.
Q: What is the maximum load power requirement for the DDC01.2-N100A-DA02-01-FW?
A: The maximum load power requirement for this drive is 18 kVA, indicating the maximum power it can handle during operation.
Q: What is the highest ambient temperature that the DDC01.2-N100A-DA02-01-FW can operate in?
A: The DDC01.2-N100A-DA02-01-FW is designed to operate in environments up to 55°C.
