The Bosch Rexroth Indramat DDC01.1-K200A-DL05-01-FW is part of the DDC Digital Intelligent Servo Drives series. This three-phase drive features air cooling by natural convection, an IP65 protection category, and a rated current of 200 Amps. It offers single axis positioning via a signal processor and supports digital servo motor feedback with a max encoder input frequency of 1 MHz.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDC01.1-K200A-DL05-01-FW is manufactured by Bosch Rexroth Indramat as part of the DDC Digital Intelligent Servo Drives series. It is a digital intelligent servo drive designed to convert numerical motion commands into controlled motor currents for industrial positioning and velocity tasks. It is suited to industrial axes in packaging, handling, and general automation equipment where commanded motion must be converted into stable motor response. A built-in command module handles single-axis interpolation, which allows the unit to execute axis moves without a separate positioning module for basic applications. The signal-processor-based control section evaluates feedback signals and generates pulse-width-modulated power for the connected motor.
This drive delivers a continuous output of 200 A on a three-phase power bus and accepts encoder feedback rates up to 1 MHz, allowing high-resolution position loops during dynamic motion. Encoder handling at this rate supports quick feedback updates when speed or direction changes rapidly. Its electronic protection trips when current rises to 1.5x rated current and when the DC link exceeds 475 V, helping reduce stress on the power stage and insulation system. The housing carries an IP65 rating and uses natural convection for cooling, so it can be mounted in dusty areas without forced airflow. Noise emission is standard for the 100 A to 200 A range rather than unusually high for this output class.
The integrated Single Axis Positioning module works with Digital Servo Feedback to close the control loop and process axis commands inside the drive. The unit provides 5 internal slots for function, communication, and memory cards, allowing additional interface options when required by the machine layout. Separate card positions let the drive support communication or memory functions without changing the base unit. Function code 05 and version 01 indicate the preset control configuration used by this model. Series 1 and hardware version 1 indicate the product revision.
Frequently Asked Questions about DDC01.1-K200A-DL05-01-FW:
Q: What is the maximum encoder input frequency supported by the DDC01.1-K200A-DL05-01-FW drive?
A: The DDC01.1-K200A-DL05-01-FW offers a maximum encoder input frequency of 1 MHz for rapid and precise feedback processing.
Q: What is the rated current specification for the DDC01.1-K200A-DL05-01-FW digital drive?
A: This model has a rated current of 200 A, suitable for demanding industrial servo applications.
Q: How many plug-in slots are available on the DDC01.1-K200A-DL05-01-FW drive?
A: The DDC01.1-K200A-DL05-01-FW features five plug-in slots for module expansion and customization.
Q: What is the protection category of the DDC01.1-K200A-DL05-01-FW drive?
A: This drive is rated with a protection category of IP65, making it protected against dust and low-pressure water jets.
Q: What type of cooling system is used in the DDC01.1-K200A-DL05-01-FW drive?
A: The cooling type for this drive is air with natural convection, eliminating the need for forced air or fans.
