Product Description:

The DDC01.1-K200A-DL04-00 is a digital intelligent servo drive engineered by Bosch Rexroth Indramat for the DDC Digital Intelligent Servo Drives series. It integrates power electronics, a DSM software module, and signal conditioning to drive brushless servo motors while processing real-time encoder data. In automated lines, the unit combines drive and control functions, and its internal logic handles positioning commands, trajectory motion, and velocity regulation so cabinet layouts can remain compact without a separate PLC. This arrangement allows the drive to manage axis motion directly while maintaining closed-loop control from the connected motor feedback.

Electrically, the inverter delivers a continuous output of 200 A, making it suitable for motors that draw high current during acceleration and sustained operation. Heat is removed by natural convection air cooling, eliminating the need for forced ventilation when ambient airflow is adequate. A command module for single-axis positioning executes homing, indexing, and dwell routines directly in the drive, while motor feedback is processed as digital servo signals to close the loop over three supply phases. Setup and diagnostics are handled through the RS232/RS485 programming interface, and the housing has an IP65 rating to protect the electronics from dust and low-pressure water spray on production floors.

The enclosure measures 220 mm in width and 298 mm in depth, which supports dense rack layouts when vertical airflow paths are kept open. Up to 3000 program blocks can be stored in nonvolatile memory, allowing the drive to hold complex motion sequences without constant external code streaming. A clearance of 300 mm above and below the unit is required to sustain convection cooling. Control wiring terminates on plug-in slots U1 through U5, and a 34-pin female connector accepts an optional display panel. The unit is function code 04, series 1, and version 1.
