Product Description:

Bosch Rexroth Indramat builds the DDC01.1-K150A-DL10-00 as part of the DDC Digital Intelligent Servo Drives series. The unit is a digital servo drive that combines power electronics and motion logic to run a single brushless motor axis in industrial automation cells. By converting line voltage into regulated three-phase output and supervising encoder data, it executes point-to-point moves, dwell times, and velocity ramps that are typical for pick-and-place gantries, packaging stations, and material-handling fixtures. Because the power stage and motion control functions are housed together, the drive supports compact axis layouts in machines that need repeatable movement.

A single-axis positioning command module allows the drive to generate trajectories without an external PLC. Continuous motor power is supported by a 150 A rated current stage, while thermal buildup is limited through natural convection air cooling that dispenses with blowers. The sealed metal housing is rated IP65, enabling direct machine mounting where dust protection and resistance to low-pressure water spray are useful. Inside, the controller stores up to 3000 program blocks, accepts four additional option cards, and provides five plug-in slots for those functions. The unit has a depth of 220 mm, and the overall height reaches 775 mm, so it fits tall cabinet layouts. Configuration uses a 34-pin female programming connector, and the drive is series 1.

An internal monitor trips the unit at 475 V DC-bus overvoltage and at 200 V undervoltage, safeguarding semiconductors during mains swings. These protection thresholds help the unit respond to supply disturbances before damaging voltage conditions reach the power section. Position and speed loops close with digital servo feedback, which gives the control section the encoder data needed for stable regulation. Acoustic output remains within the standard 100 A to 200 A noise band for this range, and a 9-pin D-Sub male service connector links to the RS-232/RS-485 port for setup and diagnostics. Panel space is conserved by a frame width of 298 mm, and the drive is version 1.
