Product Description:

The DDC01.1-K150A-DL09-01-FW is a digital intelligent servo drive manufactured by Bosch Rexroth Indramat for the DDC Digital Intelligent Servo Drives series. Designed as a compact controller, it executes positioning, velocity, and torque loops for a single servo axis in automated assembly cells, gantry systems, and material-handling lines. By integrating power electronics, motion logic, and feedback processing inside one sealed housing, the unit streamlines cabinet layouts and reduces field wiring on the factory floor. This arrangement also allows the drive to manage motion commands and motor feedback in the same enclosure, which helps support responsive axis control in space-limited installations.

Internally, the command module is configured for Single Axis Positioning, allowing the drive to carry out stored motion sequences for one controlled axis. The power stage supplies up to 150 A of continuous output current, and heat is removed by natural convection air cooling through external fins. An enclosure rated IP65 allows direct machine mounting in dusty or splash-prone areas. Parameter access is available through the RS 232/RS 485 serial interface, and a 34-Pin Female CTA connector carries encoder, enable, and I/O signals between the drive and motor. Digital servo feedback processing and the compact housing support precise motion while maintaining standard noise emission for the 100 A to 200 A class.

The drive stores up to 3000 Blocks of application code in nonvolatile memory, allowing repetitive motion tasks to run directly in the unit. It also provides 5 plug-in slots for optional interface or I/O modules, so the configuration can be adapted to the needs of the machine. Program loading is handled through a 9-Pin D-Sub port on the front panel. The assigned product revisions are function code version 01, series 1, and device version 1. These identifiers distinguish this build within the product line, while the onboard memory and modular slot arrangement support self-contained axis control without a separate motion controller for routine sequences.
