Product Description:

The DDC01.1-K050A-DL05-01-FW is a digital intelligent servo drive produced by Bosch Rexroth Indramat within the DDC Digital Intelligent Servo Drives series. It is delivered as Series 1, Version 1 and provides closed-loop power and control to synchronous servo motors used on packaging lines, handling robots, and other CNC equipment. By combining a built-in controller with drive electronics, it can execute programmed motion sequences at the axis level without relying on a separate external controller for every task, which helps simplify panel layouts in industrial automation.

The drive delivers a continuous output of 50 A, and protection against excessive load is provided by an overcurrent limit that trips above 75 A. Motor data and positioning commands can be exchanged over the RS-232/RS-485 serial interface, which supports parameter transfer and diagnostics during operation. Thermal energy is removed by natural convection air cooling, so a free air outlet clearance of 300 mm is required above the heat sink for proper airflow. The housing meets IP65, allowing the unit to be mounted directly on the machine frame in dusty or splash-prone areas. Digital servo feedback from the motor supplies position and speed information to the integrated single-axis control loop, and the internal electronics shut down if the DC bus rises above 475 V DC.

Application logic is created as program sequences, and up to 3000 blocks can be stored in memory for execution by the Single Axis Positioning command module. The system provides 5 module slots for additional I/O, fieldbus, or option cards, giving the base unit room for functional expansion when the machine requires extra interfaces. Power and encoder wiring are carried through the X30 34-pin female connector, while diagnostics and service access are routed to the X31 9-pin D-sub male port.
