The CSH01.1C-SE-EN2-EN2-NNN-S2-S-XP-FW Advanced Control System is manufactured by Bosch Rexroth Indramat. This system operates with a SERCOS Interface master communication configuration, its primary encoder option is EnDat 2.1/1 Vpp/TTL and it has two analog ouputs.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

CSH01.1C-SE-EN2-EN2-NNN-S2-S-XP-FW

  • Rated 4.3 (9 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911335447
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
The CSH01.1C-SE-EN2-EN2-NNN-S2-S-XP-FW Advanced Control System is manufactured by Bosch Rexroth Indramat. This system operates with a SERCOS Interface master communication configuration, its primary encoder option is EnDat 2.1/1 Vpp/TTL and it has two analog ouputs.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a CSH01.1C-SE-EN2-EN2-NNN-S2-S-XP-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth’s IndraDrive drive system is a safe and efficient automation solution for a wide range of applications. It has several state-of-the-art components, including drive components composed of control sections and power sections. They are used in machine tools and food packaging machines.

The CSH01.1C-SE-EN2-EN2-NNN-S2-S-XP-FW is a model of the configurable single-axis control sections in the CSH series by Bosch Rexroth. Its SERCOS master communication module guarantees maximum dynamics and precision. It also aids seamless communication between the control section and higher-level control units. Fiber optic cables are used for this connection, preventing electromagnetic interference and facilitating the secure exchange of real-time data with minimal wiring. Two encoder evaluation interfaces in the CSH control section support different encoder types with a supply voltage rating of 5V. They include the sin-cos encoder (1 Vpp) with reference track, the sin-cos encoder (1 Vpp) with EnDat 2.1 and sense lines, and the 5V-TTL square-wave encoder with reference track.

There is a standard control panel for triggering simple commands in the CSH01.1C-SE-EN2-EN2-NNN-S2-S-XP-FW. It has a single-line display with four operating keys for performing various functions. Some of the functions of the user panel include setting the transmission power of the SERCOS module, starting the basic load defaults procedure, accessing the error memory, and establishing the position data reference. The CSH control section is equipped with Safe Motion as its safety motion. It provides several application-related safety functions like safe direction, safe diagnostic outputs, safely-limited speed, and safe homing procedure. Its typical inrush current is 4A, while its maximum pulse width is 100ms. It also permits operation at switching frequencies of 2kHz, 4kHz, 8kHz, 12kHz, and 16kHz.
