CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW

  • Rated 4.5 (37 total ratings)
  • MPN: R911334338
  • Call for Expedited Shipping and Product Condition Options
The CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW Advanced Control System is manufactured by Bosch Rexroth Indramat. This system operates with a CANopen/DeviceNet master communication configuration, its primary encoder option is EnDat 2.1/1 Vpp/TTL and it has two analog ouputs.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW

  • Rated 4.5 (37 total ratings)
  • MPN: R911334338
  • Call for Expedited Shipping and Product Condition Options
The CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW Advanced Control System is manufactured by Bosch Rexroth Indramat. This system operates with a CANopen/DeviceNet master communication configuration, its primary encoder option is EnDat 2.1/1 Vpp/TTL and it has two analog ouputs.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The CSH01 product series is an advanced control section belonging to the Rexroth IndraDrive platform. Control sections are designed to be used as components of power sections, and they consist of a circuit panel with interfaces and an optional module for the configurable models. The CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW is a configurable control section used to operate HCS, HMS, and HMD drive controls. More specifically, this model is compatible with HCS02, HCS03, and all HMS drive controllers.

The CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW is equipped with optional safety technology, and it utilizes a DeviceNet, CANopen control communications with an open-style 5-pin connector. Also, its circuit board has a power consumption rating of 7.5 Watts and a typical inrush current of 4 Amperes. The CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW features an EnDat 2.1, 1Vpp, 5 V TTL encoder interface, and safe torque off safety technology. Furthermore, it is equipped with a standard operating panel that displays operating state, pending warnings, error diagnoses and helps to guide the operator through the start-up and operating procedures. Its maximum pulse width is rated at 100 ms.

The permissible transport temperature of the CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW is within the range of -25 degrees C to 70 degrees C, while its recommended storage temperature is between -25 to 55 degrees C. During storage and transportation, icing and moisture condensation are prohibited. The CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW is designed for mounting in a control cabinet, and its permissible operating temperature range is between 0 to 40 degrees C. When operating at its nominal data, the recommended installation altitude should be maintained below 1000 meters. The protection class of this unit is IP 20, and its climatic category is 3K3, as per IEC 721.

CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW Documents

  • CSH011CCOEN2NNNNNNL2SNNFW
  • CSH01 1C CO EN2 NNN NNN L2 S NN FW
  • csh01.1c-co-en2-nnn-nnn-l2-s-nn-fw

CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW Technical Specifications

Analog Outputs: 2
Master Communication: CANopen/DeviceNet
Primary Encoder Option: EnDat 2.1/1 Vpp/TTL
