CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW

  • Rated 4.5 (35 total ratings)
  • MPN: R911336022
  • Call for Expedited Shipping and Product Condition Options
The CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW Advanced Control System is manufactured by Bosch Rexroth Indramat. This system operates with a CANopen/DeviceNet master communication configuration, its primary encoder option is HSF/RSF and it has two analog ouputs.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW

  • Rated 4.5 (35 total ratings)
  • MPN: R911336022
  • Call for Expedited Shipping and Product Condition Options
The CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW Advanced Control System is manufactured by Bosch Rexroth Indramat. This system operates with a CANopen/DeviceNet master communication configuration, its primary encoder option is HSF/RSF and it has two analog ouputs.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW is an advanced control section in the Rexroth Indramat CSH01.1C series. This model is a configurable single-axis control section, and it features a type-1 design. It is designed to control and monitor electric motors efficiently. The master communication interface of this unit is the DeviceNet/CANopen type, and it comes with a traditional RS232 serial interface. Its current control has a cycle time of 62.5 – 125 microseconds. In addition, the CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW comes with two (2) analog outputs and one (1) analog input.

The typical applications of the CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW include machine tools, mounting & handling systems, packaging & food machines, paper printing & processing machines, etc. Before operating this unit, all installation and assembly conditions described by Rexroth Indramat must be fulfilled. The CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW utilizes a Safe Motion (SIL2/ cat. 3 PL d) safety option and leverages a standard control panel. It is equipped with two (2) optional encoders, and its firmware must be purchased as a separate entity. The encoders on the CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW are HSF/RSF encoder and the IndraDyn/Hiperface/1 Vpp/TTL encoder. Both encoder connection ports are tagged X4 and X8, respectively, and the power consumption of the encoders is rated at 6 Watts each.

The CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW’s standard control panel features a single line display and is operated using four control keys. This unit’s control keys can aid in the initiation of simple commands and equipment configuration. Also, some functions of the standard control panel include establishing position data reference, setting analog outputs, configuring drive address, etc. The power consumption of the CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW advanced control section is 7.5 Watts. Also, the max. pulse width of this model is rated at 100 ms, and its inrush current is 4 A.

CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW Documents

  • CSH011CCOEN1ENSNNNS2SNNFW
  • CSH01 1C CO EN1 ENS NNN S2 S NN FW
  • csh01.1c-co-en1-ens-nnn-s2-s-nn-fw

CSH01.1C-CO-EN1-ENS-NNN-S2-S-NN-FW Technical Specifications

Analog Outputs: 2
Master Communication: CANopen/DeviceNet
Primary Encoder Option: HSF/RSF
